Bussmann

Bussmann 63NHG0B Low Voltage NH Fuse, 500V, 63A, 120 kAIC, Live Gripping Lug, Ceramic Body

Low Voltage NH Fuse, 500V, 63A, 120 kAIC, Live Gripping Lug, Ceramic Body
  • MPN: 63NHG0B
  • UPC: 051712232807
  • PPN: BUS-63NHG0B

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$123.48/ EA

Description

Low Voltage NH Fuse, 500V, 63A, 120 kAIC, Live Gripping Lug, Ceramic Body

Specifications

Specifications

Fuse indicator
Combination fuse status indicator
Interrupt rating
120 kAIC
Construction size
NH0
Connection
Blade end
Material
Ceramic body
Frequency rating - max
62 Hz
Fuse type
Square body with knife blade contact
Rated switching capacity
120 kA
Breaking capacity
120 kA
Class
Class C gL/gG
Application
industrial
Special featuresLive gripping lug
ConstructionNH0
Insulated metal gripping lugs (IMGL)No
Quantity3
Amperage Rating63 A
Utilization categorygL/gG (cable protection/equipment protection)
Typefuse
Fuse shapeSquare body
Frequency rating - min45 Hz
Voltage rating500 V
Voltage typeAC

General

UPC
051712232807
Product Length/Depth
125 mm
Product Width
30 mm
Compliances
RoHS Compliant
EAN5027590485593
Product Height58 mm
Product Weight299.3333333 g
CertificationsCCC Marked
