nVent Hoffman EFA100R5 Exhaust Filter, IP54 Protection, 92x92x19mm, Thermoplastic Material
- MPN: EFA100R5
- UPC: 783510475055
- PPN: HOF-EFA100R5
CAD
$78.94
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
This vertical exhaust filter, EFA, with a IP 54 protection degree, is easy to install thanks to its click-in feature. This Exhaust Filter, EFA, EFA100R5 item measures 92x92x19mm has a material of Thermoplastic color Light Gray, finish Smooth.
Features
- Description: Exhaust filter to be used for natural ventilation, or for forced ventilation working with filter fans EF. nVent HOFFMAN exhaust filters save us time because are installed with a click-in system without screws. The hinged front cover can be easily opened for quick and easy filter replacement.
- Material: Front cover made of injection-moulded thermoplastic, self-extinguishing, UL94V0.
- Temperature range: -40 °C to +55 °C.
- Protection: IP 54, TYPE 12.
- Approvals: CE, EAC, cRUus_UL Recognized.
- Pack quantity: One exhaust filter.
- Component failure and unnecessary downtime is avoided as water and dust are prevented from entering the enclosure
- The click-in feature reduces the customer's labour cost due to the ease of installation
- To guarantee natural ventilation, install at least two exhaust filters
- Forced ventilation can be achieved by adding filter fans, EF
- Filter mat (EN779): EFA100R5, EFA200R5, EFA220R5, EFA250-300R5 - G4; EFA500-700R5 - G3
- Filtration efficiency (%): >90
Documentation & Downloads
Specifications
Key Specifications
- BABA
- Contact Manufacturer
- Width (W)
- 109
- Cutout Size
- 92 x 92
- Protection Rating
- IP54
- Material
- Thermoplastic
- Color
- Light Gray
- Weight
- 0.05
Height (H)109
Depth (D)19
Works WithClimate Control
Product FamilyClimate Control
FinishSmooth
Color CodeRAL 7035
Net Weight0.08
