Pass & Seymour 8200RED Hospital-Grade Duplex Receptacle 15A 125V, Red, 2.75 Inch Height, 1.625 Inch Width
- MPN: 8200RED
- UPC: 785007820102
- PPN: P-S-8200RED
- UNSPSC: 39121406
CAD
$13.49
/ EA
Available to Order from Manufacturer
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Hospital-Grade Duplex Receptacle 15A 125V, Red, 2.75 Inch Height, 1.625 Inch Width
Features
- One-piece nickel-plated brass mounting strap with integral ground.
- Strap tabs wrap around and lock down on face to prevent strap from separating from face and back body.
- Two drive screws anchor strap to back body and face.
- Exclusive patented feature, circuit label on face allows permanent circuit identification.
- .040 inch thick, nickel-plated brass, triple-wipe power contacts for lasting retention.
- Easily accessed break-off, line-contact connecting tab for fast, easy split-circuit wiring.
- Oversized #10 deep tri-drive head brass terminal and ground screws.
- Exclusive patented feature, external screw-pressure-plate back wire clamp on ground terminal for faster, easier installation.
- External nickel-plated screw-presure-plate back wire clamps with #10 brass terminal screws for visual assurance of a good connection.
- For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here.
- Temperature Rise: Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60°C, minimum -40°C without impact
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | Mexico |
|---|---|
| Height | 2.75 in |
| Color | Red |
| Amperage | 15.0 A |
| Indoor/Outdoor | Indoor |
| Environmental Conditions | Flammability: UL94 V2 and UL94-5 VA |
| Dielectric Strength | Withstands 2000V minimum |
| Number of Wires | 3.0 |
| Wire Size | 14 - 10 AWG |
| Operating Temperature | -40°-60°C |
| Wire Connection Type | Screw Terminals |
| Features | Brass Mounting Strap |
| Connection Location | Back and Side |
| Wall Plate Included | No |
| Depth | 0.866 in |
|---|---|
| Width | 1.625 in |
| Product Line | Pass & Seymour |
| Number of Poles | Double Pole |
| Number of Receptacles | 2.0 |
| Special Features | One-piece nickel-plated brass mounting strap with integral ground. Strap tabs wrap around and lock down on face to prevent strap from separating from face and back body. Two drive screws anchor strap to back body and face. Exclusive patented feature, circuit label on face allows permanent circuit identification. .040 inch thick, nickel-plated brass, triple-wipe power contacts for lasting retention. Easily accessed break-off, line-contact connecting tab for fast, easy split-circuit wiring. Impact-resistant nylon face and back body. Oversized #10 deep tri-drive head brass terminal and ground screws. Exclusive patented feature, external screw-pressure-plate back wire clamp on ground terminal for faster, easier installation. External nickel-plated screw-presure-plate back wire clamps with #10 brass terminal screws for visual assurance of a good connection. Line terminals accept #14 - #10 AWG stranded or solid copper-clad conductors. Auto-ground clip assures positive ground. |
| Application Sector | Healthcare; Commercial |
| Standard | cULus UL498; CSA C22.2 No. 42; FEDSPEC |
| Voltage | 125.0 V |
| Outlet Type | Hospital Grade |
| NEMA Configuration Code | 5-15R |
| Operating Temperature Min | -40.0 °C |
| Operating Temperature Max | 60.0 °C |
| Warranty Type | 1-Year Limited Warranty |
