nVent Hoffman EKOM12066-SW Compact Aluminum Enclosure 1200x600x600mm 1-Door IP66
- MPN: EKOM12066-SW
- UPC: 783510477950
- PPN: HOF-EKOM12066-SW
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Enclosure EKOM-SW is rated IP66 for outdoor and includes anti-vandalism features and high thermal management efficiency. This Compact Single Wall Version Aluminum Single And Multiple Doors, EKOM-SW, EKOM12066-SW item measures 1200x600x600mm has a material of Aluminum color Light Gray, finish Powder Coated.
Features
- Body: One piece enclosure body. Integrated depth profiles with hole pattern, allowing mounting plate adjustable in depth. The frame in multiple door versions, is divided into individual modules by means of vertical dividers.
- Rainhood: Sloped rainhood with integrated rain gutter and ventilation channels in the perimeter.
- Earthing: All panels are earthed through their fittings and are equipped with a separate earthing stud.
- "Approvals: Climatic and Chemically active substances resistance according to EN61969-3 ""Mechanical structures for electronic equipment. Outdoor enclosures”."
- Bottom plates: Supplied as accessory.
- Rear panel: Fastened from the inside. Standard facilities for rear door mounting.
- Protection: Complies with IP 66 | TYPE 4X, 12 | IK 10, when a bottom plate is fitted.
- Material: Aluminium AlMg3. Frame: 2 mm. Door: 2 mm. Rear panel: 2 mm. Rain hood: 2 mm.
- Lock: Espagnolette 4-point locking system. Does not interfere with the enclosure inner space. Standard lift handle with security lock.
- Finish: RAL 7035 structure powder coating 100% polyester.
- Door: Double walled with top and bottom ventilation openings, allowing air flow. Mounted with concealed hinges, allowing left or right hand opening. Multiple door version has individual lockable doors.
- Delivery: Frame with fitted door with swinghandle, rear panel, rain hood. Delivery also includes earthing bolts. Delivered on a pallet which is identical to the width of the enclosure to allow baying without removal. All packing material is recyclable. Mounting plate and bottom plates are not included in the standard delivery.
Documentation & Downloads
Specifications
Key Specifications
- BABA
- Contact Manufacturer
- Width (W)
- 600
- Door Quantity
- 1
- Material
- Aluminum
- Color
- Light Gray
- Thickness (T)
- 2
Height (H)1,200
Depth (D)600
Protection RatingNEMA Type 12
FinishPowder Coated
Color CodeRAL 7035
Weight45
