Mersen A2Y600-4 Form 600 Fuse 250V 600A Type 4 Blade Mount, 2.5 Inch Diameter
- MPN: A2Y600-4
- UPC: 782001909116
- PPN: FER-A2Y600-4
CAD
$1767.45
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Mersen Form 600 fuses are the original current-limiting fuses, predating all the standards. Their 500V DC rating (through 600A) is a useful feature for special fusing applications. Form 600 fuses provide a high degree of current limitation in AC and DC applications. Types 1 and 3 are dimensionally interchangeable with Class H and K fuses. Types 4 and 5 have unique rejection dimensions and are not interchangeable.
Specifications
Key Specifications
- Rated voltage AC UL
- 250 V
- Frequency (Hz)
- 50/60 Hz
- ROHS Compliant
- Yes
- Mounting
- Clip
- Connection/Terminal Material
- Silver-Plated Copper
- Body/Insulating Material
- GMG
- Length
- 10.38 in
Rated voltage DC UL500 V
Ampere Rating600 A
AC or DCAC/DC
AC Max I.R./Breaking Capacity: I1200 kA
Connection/Terminal TypeBlade
L/R (ms)10 ms
Weight3.4 lb
