Thomas & Betts MCAN-5B25-22 FUSE CANISTER, 25 KV, 2.25X14.37
- MPN: MCAN-5B25-22
- UPC: 783786290406
- PPN: T-B-MCAN-5B25-22
- UNSPSC: 26121630
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Fuse Canister for Fuses HTFX240003, HTFX240006, HTFX240008, HTFX240010, HTFX240012, HTFX240018, HTFX240020, HTFX240025, HTFX240030, HTFX240040 and HTFX240050, 25.80 inches long. 15.5kV, 3-50 Amps. 200 Amp Bushing Wells on each end
Specifications
Ordering
| Country of Origin | United States (US) |
|---|
| Selling Unit of Measure | each |
|---|
Additional Information
| Application | Padmount, Subsurface and Vault Applications |
|---|---|
| Effective Date | 20010823 |
| Product Name | ELECTRICAL FUSE>1000V |
| Size | 25.80 inch Length |
| Standards | ANSI C37.40, ANSI C37.41, ANSI C37.47, ANSI/IEEE 386 |
| Brand / Label | Elastimold |
|---|---|
| Material | EPDM Rubber Housing |
| Product Type | Molded Canister Fuses |
| Special Functions | Fuses are Fully Sealed and Submersible |
| Temperature Range | -30 to + 65 °C |
Classifications
| WEEE Category | Product Not in WEEE Scope |
|---|
| IDEA Granular Category Code (IGCC) | 1779 >> Cable accessories |
|---|
