Mersen USGM4 Fuse Holder UltraSafe™ 750VAC 1000VDC Midget 30A 4-Pole Cage Clamp IP20
- MPN: USGM4
- UPC: 782001437916
- PPN: FER-USGM4
CAD
$162.39
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Mersen’s USGM series fuse holders deliver the ultimate ease-of-use, time (labor) saving and reliable solution available in the marketplace. Mersen is the first manufacturer to offer screw-less, spring pressure, wire termination technology into a power fuse holder, delivering the best of both technologies to its customers. Now you can experience the combined benefits of safety, ease-of-use, labor savings and reliability of UltraSafe fuse holders and spring pressure technology.
Specifications
Key Specifications
| Rated voltage AC UL | 750 V |
|---|---|
| Frequency (Hz) | 50/60 Hz |
| ROHS Compliant | Yes |
| Fuse Class | Midget |
| Fuse Type/Class | Midget |
| Wiring range | #6 to #14 Solid or Stranded |
| Max Fuse Rating | 30 A |
| Body/Insulating Material | Polyamide |
| Length | 4.13 in |
| Weight | 0.56 lb |
| Rated voltage DC UL | 1000 V |
|---|---|
| Ampere Rating | 30 A |
| AC or DC | AC/DC |
| Short Circuit Current Rating (SCCR) | 200 kA |
| Number of Poles | 4-Pole |
| Fuse Installation Method | Clip-in |
| Installation Mounting | DIN Rail |
| Width | 2.72 in |
| Height | 2.17 in |
