Tripp Lite N785-P01-SC-MM1 Gigabit Multimode Fiber to Ethernet Converter, PoE+, 550 m, SC
- MPN: N785-P01-SC-MM1
- UPC: 037332236913
- PPN: TRP-N785-P01-SC-MM1
CAD
$334.26
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Gigabit Multimode Fiber to Ethernet Converter, PoE+, 550 m, SC
Features
- Extends power (48 VDC) + data (1000 Mbps) to any edge PoE+ device
- Supports multimode fiber optic cable with SC connectors up to 550 m (1804 ft.)
- RJ45 jack supports auto-MDI/MDIZ to bridge various network devices
- Supports both full- and half-duplex operation
- Works in tandem with Tripp Lite N785-001-SC-MM (sold separately)
- Extends Power and Data to a PoE+ Device up to 550 Meters via SC Multimode Fiber Cable
- Supports Power over Ethernet to Save You Money and Give You More Installation Choices
- Supports Auto-Sensing of Network Speed and Other Advanced Functions
- Works in Tandem with Tripp Lite’s N785-001-SC-MM Media Converter
- Completely Plug-and-Play with No Additional Software Required for Connection
Documentation & Downloads
Specifications
Additional
- Power
- 48 VDC, 1.25A
- Transmission Distance
- 550 m (1804 ft.)
- Working Mode
- Full/Half Duplex
- Unit Dimensions (H x W x D)
- 0.98 x 3.74 x 2.76 in
- Connector Type A
- RJ45 (Female)
- Power Supply Input
- 100-240 V~ 50/60 Hz, 1.5 A
- Storage Temperature Range
- -4 to 158 F (-20 to 70 C)
- Relative Humidity
- 5% to 90% RH, Non-Condensing
- External Power Supply Certifications
- CCC, FCC, PSE, UL, cUL
Network Speed1 Gbps
Wavelength850 nm
Mode TypeMultimode
Unit Weight0.44 lbs
Connector Type BSC Duplex (Female)
Power Supply Cord Length3.6 ft
Operating Temperature Range-4 to 140 F (-20 to 60 C)
ColorBlack
External Power Supply Plug(s)NEMA 5-15P North America
