RFID Data Carrier Ø 50 x 3.3 mm, 13.56 MHz, 2000 Byte Memory

Documentation & Downloads

Balluff BIS M-112-02/L-SA1 RFID Data Carrier Ø 50 x 3.3 mm, 13.56 MHz, 2000 Byte Memory

MPN: BIS M-112-02/L-SA1
PPN: BAL-BIS0158

CAD

$37.93

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Company Stock:

Qty:

Loading add to cart quantity...

Looking to buy a large quantity?

To view product inventory

Spec sheet

Compare

Description

BIS M uses high frequency (HF) 13.56 MHz and supports the standard according to DIN ISO 15693 and/or DIN ISO 14443. The wide variety of passive data carriers with various dimensions, configurations, memory sizes, operating temperatures, materials, antenna technology, mounting options and ranges allows you to tackle nearly any technical task. BIS M is the most robust system with absolute data security.

Documentation & Downloads

Specifications

Additional

Frequency: 13.56 MHz

UID Serial Number: 8 Byte

User Data Read/Write: 2000 Byte

Storage Temperature Range: -25 to 85 0C

Dimensions: 8 50 x 3.3 mm

Installation: metal-free (clear zone)

IP Rating: IP68, IPx9K (DIN 40050)

Memory Size2000 Byte

Memory TypeFRAM

Ambient Temperature Range-25 to 85 0C

Temporary Storage Temperature140 0C (1x100 h), -40 to 90 0C (1x1000 h)

Antenna TypeRound

Housing MaterialPA 6

Approval/ConformityCE, Ecolab, WEEE
