nVent Hoffman OICE505021 HMI Enclosure, 500 x 500 x 210 mm, Mild Steel, IP55 Protection

MPN: OICE505021
UPC: 783510524227
PPN: HOF-OICE505021

$1459.23

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

It has a pre-machined hole pattern to allow the fixation of a swing arm and a removable front plate at IP 55 protection. This Operator Interface Control Enclosure, OICE, OICE505021 item measures 500x500x210mm has a material of Mild Steel color Light Gray, finish Powder Coated.

Features

Material: Body and door are manufactured from 1.2 mm mild steel, front cover and handles manufactured from aluminium.
Body: Folded and seam welded, with maximum opening. The front fitted with an aluminium front panel. Handling grips mounted to front, left and right edges.
Rear door: Surface mounted, with 130° opening. Concealed removable hinges, with captive pin. Hinges can be mounted to allow left or right hand opening. Door profiles MMDP are available as an accessory.
Lock: Customised lock, with double grip for easy opening of the door. Double-bit 3 mm insert and 90° movement. Other inserts and locks are available as an accessory.
Protection: IP 55, IK 10.
Finish: RAL 7035 structured powder coating. Top bottom profile RAL7016.
Delivery: Enclosure with aluminium front panel, rear door, plastic double-bit 3 mm key and mounting accessories.
