nVent Hoffman HR1626423 Top-Mount Filter Fan 230V 348 CFM Graphite Black Mild Steel 12.66 x 15.81 x 4.18 Inch
- MPN: HR1626423
- UPC: 783510385088
- PPN: HOF-HR1626423
- UNSPSC: 40101604
CAD
$1401.08
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
HR Top-Mount Filter Fans bolt in place to the top of enclosure ensuring a tight seal. This HR16 Top-Mount Filter Fan, HR1626423 item is rated 230V 348 CFM with a material of Steel colored Black.
Features
- Enclosure top mounting
- Bolt in place to ensure a tight seal
- Terminal block connections
- Free airflow up to 266 CFM (452 m3 /hr.) or 348 CFM (591 m3 /hr.)
Documentation & Downloads
Specifications
Key Specifications
| BABA | Contact Manufacturer |
|---|---|
| Nominal Voltage | 230 |
| Width (W) | 402 |
| Max Current | 0.53 |
| Material | Mild Steel |
| Color Code | RAL 9011 |
| Size | 12.66 x 15.81 x 4.18 inch |
| Flow Rate | 311 |
| Frequency Rating | 50/60 Hz |
| Amperage Rating | 0.53 |
| Fan Speed | 2650 |
| Mounting | Top Mount |
| Motor Insulation | TOTALLY ENCLOSED WITH CLASS F INSULATION |
| Ambient Temperature | 14-131 F |
| Finish | Powder Coated |
| Airflow | 591 |
|---|---|
| Height (H) | 322 |
| Depth (D) | 106 |
| Operating Temperature | -10 |
| Color | Graphite Black |
| Weight | 2 |
| Blade Size | 8.78 |
| Voltage Rating | 230 Volts |
| Phase | 1-phase |
| Power | 107 |
| Sound Pressure Level | 68 |
| Motor Type | AC |
| Shaft Diameter | 1.063 inch |
| Housing Material | Mild Steel |
| Blade Material | Polyamide 66 Resin |
