Brady 59928 HTRL LIQ AMMONIA LOW Pipe Marker, 4" H x 24" W, Fits Pipes 8" Dia. or Larger
- MPN: 59928
- UPC: 754473599287
- PPN: BRD-59928
- UNSPSC: 55121737
CAD
$78.99
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
These IIAR-compliant pipe markers come with the traditional yellow background and are recommended for use in labeling ammonia piping and its contents.
Features
- IIAR pipe markers should include: the marker body (AMMONIA), physical state, pressure level, directional arrows, and an ammonia piping abbreviation
- Style HPHV (High Performance High Visibility) pipe markers are supplied on a fiberglass plastic carrier and are ideal for 8" and larger pipe diameters
- Designed for use on rusty, dirty, wet or rough surfaces and can be used indoors or outdoors on horizontal and vertical pipes
- Pipe marker includes directional arrows
Specifications
Key Specifications
| Applications | Pipe and Valve Marking |
|---|---|
| Color | Black/Green/Orange on Yellow |
| Enables Industry Compliance | ANSI A13.1-2007 |
| IIAR Phase | LIQ |
| IIAR System Abbreviation | HTRL |
| Pipe Marker Mounting Style | Fiberglass Carrier |
| Pre-Printed Areas on Label | IIAR Legend |
| Brady Material Number | B-681/B-883 |
| Laminated | Laminated |
| Material Properties | High Visibility; Rigid |
| SAP B-Number | B-681/B-883 |
| Character Height (in/ft/yd) | 3.5 in |
| Dimensions | 4 in H x 24 in W |
| Dimensions 2 | 4 in H x 24 in W |
| Height (mm/cm/m) | 101.6 mm |
| Maximum Service Temperature °F | 230 °F |
| Minimum Outside Pipe Diameter (mm/cm/m) | 203.2 mm |
| Minimum Service Temperature °F | -40 °F |
| Roll/Tape Size (in/ft/yd) | 4 in H x 24 in W |
| Size | HPHV |
| Width (mm/cm/m) | 60.96 cm |
| Brand Name | Brady® |
|---|---|
| Combined IIAR Legend | AMMONIA HTRL LIQ LOW |
| IIAR Legend | AMMONIA |
| IIAR Pressure Level | LOW |
| Language | English |
| Pipe Marker Style | HPHV |
| Primary Noun, Basic Function | Pipe Marker |
| Indoor or Outdoor Use | Outdoor Use |
| Material | Polyester Overlaminate on Fiberglass Plastic Carrier |
| Resistance Properties | Abrasion-Resistant; Chemical-Resistant |
| Average Outdoor Durability | 5 to 8 Years |
| Character Height (mm/cm/m) | 88.9 mm |
| Dimensions (Metric) | 101.6 mm H |
| Height (in/ft/yd) | 4 in |
| Maximum Service Temperature °C | 110 °C |
| Minimum Outside Pipe Diameter (in/ft/yd) | 8 in |
| Minimum Service Temperature °C | -40 °C |
| Overall Size | Fits Pipes 8" Dia. or larger |
| Sign Size-General | 4 in x 24 in |
| Width (in/ft/yd) | 24 in |
Regulatory Information
| Contains CA PROP 65 Substance | No - Does not contain |
|---|---|
| Contains Heavy Metal(s) | Unavailable |
| EU RoHS Compliance | Not Applicable |
| SDS Safety Data Sheet required | No = MSDS/SDS is not required |
| Contains CA PROP 65 Substance | No |
|---|---|
| DOT Regulated Product | No = not regulated by DOT |
| EU RoHS Compliant | No |
