Square D HCJ50916 Interior I-Line Panelboard 600A Main Lugs 99 Inch CB Space 32 Inch W x 66.03 Inch H
Square D HCJ50916 Interior I-Line Panelboard 600A Main Lugs 99 Inch CB Space 32 Inch W x 66.03 Inch H
- MPN: HCJ50916
- UPC: 785901476153
- PPN: SCH-HCJ50916
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To view product inventory
CAD$2026.17/ EA
Description
This interior I-Line panelboard by Schneider Electric offers a robust solution for power distribution, designed to efficiently manage electrical systems in various settings. With a 600-amp main lug capacity, it provides substantial support for high-demand applications, featuring a spacious 99-inch circuit breaker space. The panelboard's dimensions, at 32 inches wide and 66.03 inches high, ensure that it fits well into standard installations while optimizing access and organization of electrical components. Engineered for durability and reliability, this panelboard is a vital component for effective load management in industrial and commercial environments.
Specifications
- Rated Current
- 600 A
- Circuit Breaker Type
- B-Frame, J-frame, H-frame, Q-Frame, QO
- Width
- 26.45 in
- Depth
- 8.75 in
- Material
- painted steel
- Main Type
- Main lugs
- Compliance
- EU RoHS Compliant, China RoHS Declaration
- Mercury Free
- Yes
- Sustainable Offer Status
- Green Premium product
- Range Of Product
- I-Line
- Bar Length
- 99 in
- Circularity Profile
- N/A
- Reach Regulation
- Free of SVHC above threshold
Number of Phases3 phases
Circuit Breaker Space99 in
Height66.03 in
Tightening Torque37.96 N.m (335.97 lbf.in) AWG 2/0...500 kcmil
Enclosure Typedistribution enclosure
Product CertificationscULus
Toxic Heavy Metal FreeYes
REACH SVHC FreeYes
Product Or Component Typeinteriors
Environmental DisclosureENVPEP1409018EN
Localisation On Deviceinterior
Product Destinationenclosure HCJ 32 in 91 in 9.5 in
Network Number Of Phases3 phases
