Pass & Seymour IG420HISP Isolated Ground Hospital Grade Quad Receptacle 20A 125V Ivory
Pass & Seymour IG420HISP Isolated Ground Hospital Grade Quad Receptacle 20A 125V Ivory
- MPN: IG420HISP
- UPC: 785007125740
- PPN: P-S-IG420HISP
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$189.66/ EA
Description
Isolated Ground Hospital Grade TVSS Quad Receptacle, 20A 125V
Features
- Rugged nylon face and body withstands impacts and hard use.
- Built-in wire stripping gauge.
- Outward-facing ground terminals make handling up to four straight or angled plugs easy and convenient.
- Heavy-duty, phosphor bronze contacts.
- Shielding walls guard against live-circuit-to-ground shorts.
- Split circuit break-off tabs.
- UL and CSA listed.
- For covering patents, see www.legrand.us/patents.
Specifications
Specifications
- Country of Origin
- Mexico
- Product Line
- Pass & Seymour
- Amperage
- 20.0 A
- Mounting Type
- Box
- Number of Wires
- 3.0
- Indoor/Outdoor
- Indoor
- Wall Plate Included
- No
- Number of Receptacles
- 4.0
- Outlet Type
- Isolated Ground
- Features
- Brass Mounting Strap
- Connection Location
- Back and Side
- Warranty Type
- 1-Year Limited Warranty
- Environmental Conditions
- Flammability: UL94 V2 and UL94-5 VA
ColorIvory
Special FeaturesGreen LED Indication: ON when protection is active, OFF when protection is inactive. IG symbol and Isolated Ground markings for easy identification and circuit delineation. Rugged nylon face and body withstands impacts and hard use. Built-in wire stripping gauge. Outward-facing ground terminals make handling up to four straight or angled plugs easy and convenient. Heavy-duty, phosphor bronze contacts. Shielding walls guard against live-circuit-to-ground shorts. Split circuit break-off tabs.
StandardUL1449
Voltage125/250 V
Outlet TypeLocking
Wire Size14 - 12 AWG
FeaturesIndicator Lights
Number of PolesDouble Pole
Application SectorCommercial
NEMA Configuration Code5-20R
Wire Connection TypeScrew Terminals
StandardUL498: ANSI/EEE C62.41 (Formerly IEEE 587)
StandardANSI/IEEE C62.45 Installation Categories “A” (Ring Wave) “B” (Unidirectional Impulse).
