Balluff BIS L-6026-034-050-06-ST19 LF processor units (125 kHz) BIS L-6026-034-050-06-ST19
Balluff BIS L-6026-034-050-06-ST19 LF processor units (125 kHz) BIS L-6026-034-050-06-ST19
- MPN: BIS L-6026-034-050-06-ST19
- PPN: BAL-BIS00EF
Spec sheet
Loading compare button...
Available to Order
Company Stock:
0
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$4516.08/ EA
Description
BIS L uses the low frequency (LF) 125 kHz and uses passive data carriers. The processor units process the data recorded by the read heads and relay it to the industrial fieldbus, which communicates with the PLC/PC. With type BIS V processor units, you can operate up to four read heads at once – regardless of whether they are LF, HF or UHF.
Specifications
Specifications
- Product Group
- LF (125 kHz)
- Supported RFID technologies
- LF 125 kHz (BIS L)
- Operating voltage Ub
- 19.2-28.8 VDC
- Ambient temperature
- 0-60 °C
- Approval/Conformity
- CE, cULus, WEEE
InterfaceEtherNet/IP
Number of connectable R/W heads / antennas2
Housing materialAluminum, Die casting
IP ratingIP65 with connector
ConnectionFemale, 4-pin, D-codedMale, 5-pin
