Telemecanique Sensors XCMD21G1M12 Limit switch, Limit switches XC Standard, XCMD, M16 metal roller plunger nitrile boot, 1C/O, snap, M12

MPN: XCMD21G1M12
PPN: TES-XCMD21G1M12

$293.08

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

Limit switch, Limit switches XC Standard, XCMD, M16 metal roller plunger nitrile boot, 1C/O, snap, M12

Documentation & Downloads

Specifications

Key Specifications

Movement Of Operating Head	linear
Fixing Mode	by the head
Sensor Design	miniature
Head Material	zamak
Head Type	M16 plunger head
Series Name	standard format
Body Type	plug-in body
Body Material	zamak
Number Of Poles	1

Range Of Product	Telemecanique Limit switches XC Standard
Type Of Operator	spring return roller plunger metal with elastomer boot
Product Or Component Type	limit switch
Material	metal
Type Of Approach	vertical approach, 1 direction
Contacts Type And Composition	1 C/O
Contact Operation	snap action
Device Short Name	XCMD

Complementary

Height	50-50 mm
Minimum Actuation Speed	0.01 m/min
[Ithe] Conventional Enclosed Thermal Current	3 A
[Uimp] Rated Impulse Withstand Voltage	2.5 kV IEC 60664 \|\| 2.5 kV IEC 60947-1
[Ui] Rated Insulation Voltage	250 V 3)IEC 60947-5-1
Positive Opening	without
[Ie] Rated Operational Current	1.5 A 240 V, AC-15 EN/IEC 60947-5-1 appendix A \|\| 0.1 A 250 V, DC-13 EN/IEC 60947-5-1 appendix A
Maximum Actuation Speed	0.5 m/s
Width	30 mm
Maximum Resistance Across Terminals	25 mOhm IEC 60255-7 category 3

Short-Circuit Protection	4 A cartridge fuse gG
Electrical Connection	male connector M12, 4 pins
Net Weight	0.125 kg
Switch Actuation	on end
Electrical Durability	5000000 cycles, DC-13, 24 V, 3 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C \|\| 5000000 cycles, DC-13, 48 V, 2 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C \|\| 5000000 cycles, DC-13, 120 V, 1 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C
Contacts Insulation Form	Za
Mechanical Durability	10000000 cycles
Minimum Force For Tripping	8.5 N
Depth	16 mm

Environment

Product Certifications	UL \|\| CCC \|\| CSA
Ambient Air Temperature For Operation	-25-70 °C
Shock Resistance	25 gn 18 ms IEC 60068-2-27
Ip Degree Of Protection	IP66 conforming to IEC 60529 \|\| IP67 conforming to IEC 60529 \|\| IP68 conforming to IEC 60529
Electrical Shock Protection Class	class I IEC 61140 \|\| class I NF C 20-030

Ik Degree Of Protection	IK06 EN 62262
Standards	EN/IEC 60947-5-1 \|\| UL 508 \|\| EN/IEC 60204-1 \|\| CSA C22.2 No 14
Vibration Resistance	5 gn 10-500 Hz)IEC 60068-2-6
Ambient Air Temperature For Storage	-40-70 °C
Protective Treatment	TC

Contractual warranty

Warranty	18 months

Offer Sustainability

Rohs Exemption Information	Yes
Environmental Disclosure	ENVPEP110612EN
Reach Regulation	Reference contains Substances of Very High Concern above the threshold
Circularity Profile	ENVEOLI110612EN

Mercury Free	Yes
Sustainable Offer Status	Green Premium product
California Proposition 65	WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Eu Rohs Directive	Pro-active compliance (Product out of EU RoHS legal scope)
