Burndy YAZ322TC38FX Long Length Barrel Terminal, 2 Hole, 300 kcmil, Red, 3/8 Inch Stud
- MPN: YAZ322TC38FX
- UPC: 781810228616
- PPN: BUR-25019232
CAD
$105.95
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
2 Hole HYLUG Cu Compr Terminal, Long Brrl, W/ Insp Window, 313.1(775/#24) DLO, 300 kcmil, 3/8" stud, 1" spacing, Red, 18 or 324 Index
Documentation & Downloads
Specifications
Dimensions
| Dimension - B Length fraction | 2-1/8 in |
|---|---|
| Dimension - Bolt Hole Size inch | 0.39 in |
| Dimension - D inch | 1.84 in |
| Dimension - Hole Size mm | 10 mm |
| Dimension - Length Overall inch | 4.62 in |
| Dimension - N inch | 0.41 in |
| Dimension - Pad Width inch | 1.40 in |
| Dimension - Thread Size | 3/8 |
| Physical Attribute - Tongue Angle | Straight |
| Dimension - B Length inch | 2.12 in |
|---|---|
| Dimension - Bolt Size fraction | 3/8 |
| Dimension - Hole Size inch | 0.40 in |
| Dimension - L Length Overall mm | 117 mm |
| Dimension - Length Side B inch | 4.62 in |
| Dimension - Outside Diameter inch | 0.95 in |
| Dimension - Strip Length inch | 2-3/16 |
| Dimension - Z inch | 0.43 in |
Certifications and Compliance
| Certification - CSA Approved | Yes |
|---|---|
| Certification - UL Recognized | No |
| Standards - RoHS Compliance Status | CM |
| Certification - ETL | No |
|---|---|
| Certification - cULus | No |
| UL Listed | Yes |
Conductor Related
| Conductor - Copper DLO Size | 313.1 (775/#24) DLO |
|---|---|
| Conductor - Copper Flex G Size | 300 kcmil |
| Conductor - Copper Flex H Size | 300 kcmil |
| Conductor - Copper Flex I Size | 300 kcmil |
| Conductor - Copper Flex K Size | 300 kcmil |
| Conductor - Copper Flex M Size | 300 kcmil |
| Conductor - Material | Copper |
| Conductor - Copper DLO Size Range | 313.1 (775/#24) DLO |
|---|---|
| Conductor - Copper Flex G Size Range | 300 kcmil |
| Conductor - Copper Flex H Size Range | 300 kcmil |
| Conductor - Copper Flex I Size Range | 300 kcmil |
| Conductor - Copper Flex K Size Range | 300 kcmil |
| Conductor - Copper Flex M Size Range | 300 kcmil |
General
| Color Code | Red |
|---|---|
| Die Index | 18;324 |
| Feature - Barrel Type | Long |
| Physical Attribute - Number of Holes | 2 |
| Plating Type | Tin |
| Trade Name | HYLUG™ |
| UPC | 781810228616 |
| Connector Type | Terminal |
|---|---|
| Feature - Barrel Style | Skived |
| Material | Copper |
| Plated | Y |
| Temperature Rating | 194 |
| Type | Long Barrel, Skive |
| UPC 12 Digit | 7818102286166 |
Electrical Ratings
| Rating - KVA | 35 kV |
|---|---|
| Voltage - Maximum | 35000 |
| Rating - Minimum Voltage | 600 |
|---|
Logistics
| Minimum Pack Quantity | 10 |
|---|
