Burndy YAZ342TC14E2FX Long Length Barrel Terminal, 2 Holes, 350 kcmil Copper, 1/4 Inch Stud, Blue
- MPN: YAZ342TC14E2FX
- UPC: 781810324189
- PPN: BUR-10016341
CAD
$68.25
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
2 Hole HULYG Cu Compr Terminal, Long Brrl, W/ Insp Window, 373.7 (925/ #24) DLO, 350 kcmil Flex, 1/4" stud, .75" spacing, Blue, 19 or 470 Index
Documentation & Downloads
Specifications
Dimensions
| Dimension - B Length fraction | 2-1/4 in |
|---|---|
| Dimension - Bolt Hole Size inch | 0.27 in |
| Dimension - Hole Size inch | 0.27 in |
| Dimension - L Length Overall mm | 112 mm |
| Dimension - Length Side B inch | 4.42 in |
| Dimension - Outside Diameter inch | 1.06 in |
| Dimension - Strip Length inch | 2-5/16 |
| Physical Attribute - Tongue Angle | Straight |
| Dimension - B Length inch | 2.25 in |
|---|---|
| Dimension - Bolt Size fraction | 1/4 |
| Dimension - Hole Size mm | 7 mm |
| Dimension - Length Overall inch | 4.42 in |
| Dimension - N inch | 0.31 in |
| Dimension - Pad Width inch | 1.55 in |
| Dimension - Z inch | 0.34 in |
Certifications and Compliance
| Certification - CSA Approved | Yes |
|---|---|
| Certification - UL Recognized | No |
| Standards - RoHS Compliance Status | CM |
| Certification - ETL | No |
|---|---|
| Certification - cULus | No |
| UL Listed | Yes |
Conductor Related
| Conductor - Copper DLO Size | 373.7 (925/#24) DLO |
|---|---|
| Conductor - Copper Flex G Size | 350 kcmil |
| Conductor - Copper Flex H Size | 350 kcmil |
| Conductor - Copper Flex I Size | 350 kcmil |
| Conductor - Copper Flex K Size | 350 kcmil |
| Conductor - Copper Flex M Size | 350 kcmil |
| Conductor - Material | Copper |
| Conductor - Copper DLO Size Range | 373.7 (925/#24) DLO |
|---|---|
| Conductor - Copper Flex G Size Range | 350 kcmil |
| Conductor - Copper Flex H Size Range | 350 kcmil |
| Conductor - Copper Flex I Size Range | 350 kcmil |
| Conductor - Copper Flex K Size Range | 350 kcmil |
| Conductor - Copper Flex M Size Range | 350 kcmil |
General
| Color Code | Blue |
|---|---|
| Die Index | 19;470 |
| Feature - Barrel Type | Long |
| Physical Attribute - Number of Holes | 2 |
| Plating Type | Tin - Electro Plated |
| Type | Long Barrel, Skive |
| UPC 12 Digit | 7818103241899 |
| Connector Type | Terminal |
|---|---|
| Feature - Barrel Style | Skived |
| Material | Copper |
| Plated | Y |
| Trade Name | HYLUG™ |
| UPC | 781810324189 |
Electrical Ratings
| Rating - KVA | 35 kV |
|---|---|
| Voltage - Maximum | 35000 |
| Rating - Minimum Voltage | 600 |
|---|
Logistics
| Minimum Pack Quantity | 6 |
|---|
