Documentation & Downloads
Balluff BFT 6025-JC003-A02A0C-S4 Media-Contacting Temperature Sensor, -20 to 80 °C, 1/2 Inch NPT, IP65/IP67
- MPN: BFT 6025-JC003-A02A0C-S4
- PPN: BAL-BFT0018
CAD
$673.87
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Media-Contacting Temperature Sensor, -20 to 80 °C, 1/2 Inch NPT, IP65/IP67
Documentation & Downloads
Specifications
Additional
- Measuring Range
- -20 to 80 B0C
- Pressure Rating Max.
- 150 bar
- Switching Output
- PNP
- Process Connection
- 1/2 in NPT, outer
- Housing Material
- PC/ABS, TPE-E, Stainless Steel (1.4301)
- Measuring Element
- Pt1000
- Connection
- Connector, M12x1-Male, 4-pin
Operating Voltage15 to 35 VDC
Analog Output4 to 20 mA
Installation Length from Contact Surface25 mm
Process Connection MaterialStainless Steel (1.4571)
IP RatingIP65, IP67
Ambient Temperature-20 to 80 B0C
Approval/ConformityCE, cULus, WEEE
