Balluff BFT 6025-JC003-D00A0C-S4 Media-contacting temperature sensors BFT 6025-JC003-D00A0C-S4
Balluff BFT 6025-JC003-D00A0C-S4 Media-contacting temperature sensors BFT 6025-JC003-D00A0C-S4
- MPN: BFT 6025-JC003-D00A0C-S4
- PPN: BAL-BFT001L
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$654.25/ EA
Specifications
Specifications
- Measuring range
- -20-80 °C
- Operating voltage Ub
- 15-35 VDC
- Connection
- Connector, M12x1-Male, 4-pin
- Process connection
- NPT 1/2" outer
- Housing material
- PC/ABSTPE-E, PC, Stainless steel (1.4301)
- Ambient temperature
- -20-80 °C
- Approval/Conformity
- CE, cULus, WEEE
Measuring elementPt1000
Switching output2x PNP
Installation length from contact surface25 mm
Process connection materialStainless steel (1.4571)
Pressure rating max.150 bar
IP ratingIP65, IP67
