Schneider Electric MH31002P01A2200 servo motor MH3 100 5,8Nm,no key,single,no brake,IP65/IP67,4kRPM

MPN: MH31002P01A2200
PPN: SCH-MH31002P01A2200

Spec sheet

In Stock

Company Stock:

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$1894.17/ EA

Qty:

Loading add to cart quantity...

Description

servo motor MH3 100 5,8Nm,no key,single,no brake,IP65/IP67,4kRPM

Specifications

Physical Attributes

Motor Flange Size: 100 mm

Shaft Length40 mm

Complementary Attributes

Maximum Radial Force Fr: 990 N 1000 rpm, 790 N 2000 rpm, 690 N 3000 rpm, 620 N 4000 rpm, 580 N 5000 rpm

Maximum Mechanical Speed: 6000 rpm

Maximum Current Irms17.4 A

Us Rated Supply Voltage115...480 V

Important Information Attributes

Nominal Speed: 2000 rpm LXM62 4.58 mA, 230 V, single phase, 4000 rpm LXM62 4.1 mA, 400 V, three phase, 5000 rpm LXM62 3.73 mA, 480 V, three phase, 1000 rpm LXM52 4.81 mA, 115 V, single phase, 2000 rpm LXM52 4.58 mA, 230 V, single phase, 4000 rpm LXM52 4.1 mA, 400 V, three phase, 5000 rpm LXM52 3.73 mA, 480 V, three phase, 1000 rpm LXM62 4.81 mA, 115 V, single phase

Local Data Status: Publishable

Global Commercial Status: Commercialised

Stocking Flag: Y

Device Type: Motion - drive & motor

Traceability: Yes

Average Life Duration: 15 year(s)

Scope Perimeter: At least in Europe

Rohs Eur In Scope: No

Rohs Eur Conformity Date: 1901

China Rohs In Scope: Yes

With Recycled Cardboard: No

Product Contributes To Saved And Avoided Emissions: No

Centring Collar Diameter: 95 mm

Continuous Power: 2270 W

Continuous Stall Torque: 6 N.m, 115...480 V, three phase

Electrical Connection: rotatable right-angled connectors

Holding Brake: without

Mounting Support: international standard flange

Number Of Mounting Holes: 4

Phase: three phase

Product Or Component Type: servo motor

Rotor Inertia: 6.28 kg.cm²

Shaft Diameter: 19 mm

Sizing Reference: MH31002P

Stator Electrical Time Constant: 5 ms

Stator Resistance: 1.97 Ohm

Temperature Copper Hot: 135 °C

Type Of Cooling: natural convection

Pep Code: ENVPEP111002EN

Length Total: 160.6 mm

Nominal Torque5.33 N.m LXM62 4.58 mA, 230 V, single phase, 4.67 N.m LXM62 4.1 mA, 400 V, three phase, 4.2 N.m LXM62 3.73 mA, 480 V, three phase, 5.67 N.m LXM52 4.81 mA, 115 V, three phase, 5.33 N.m LXM52 4.58 mA, 230 V, single phase, 4.67 N.m LXM52 4.1 mA, 400 V, three phase, 4.2 N.m LXM52 3.73 mA, 480 V, three phase, 5.67 N.m LXM62 4.81 mA, 115 V, single phase

Local Publishable Date2026-01-12

Return IndicatorN

Stock Policy2

ServiceabilityYes

Field Service DivisionIDIBS

Legacy Weee ScopeOut

Eoli Availability DisplayNo need of specific recycling operations

Rohs Eur StatusCompliant By Exemption

Rohs Eur Full Compliance StatusCompliant By Exemption

China Rohs Label5

Without Single Use PlasticNo

Product Kit IdentifierN

Circle Diameter Of The Mounting Holes115 mm

Continuous Stall Current5.04 A

Device Short NameMH3

Encoder Typesingle turn SinCos Hiperface

Mounting Holes Diameter9 mm

Number Of Motor Poles10

Peak Stall Torque18 N.m, 115...480 V, three phase

Product AvailabilityNon-Stock - Not normally stocked in distribution facility

ReturnabilityNo

Second Shaftwithout second shaft end

Shaft Endsmooth shaft

Speed Feedback Resolution128 periods

Stator Inductance8.24 mH

Sustainable PackagingNo

Torque Constant1.19 N.m/A 120 °C

Warranty In Months18

Offer Owner Code190786

Environment Attributes Main

Take Back: Nej

China Rohs Regulation: X

Environmental Disclosure: ENVPEP111002EN

Ip Degree Of Protection: IP65 standard

Packaging Without Single Use Plastic: No

Recycled Metal Content At Cr Level0 %

Mercury FreeYes

Eu Rohs DirectiveCompliant By Exemption

Packaging Made With Recycled CardboardNo

Pep CodeENVPEP111002EN

General Attributes

Phase: three phase

Product Or Component Typeservo motor

ETIM

ETIM 8: EC001851

ETIM 9EC001851

Output Attributes

Nominal Output Power: 0.59 W, 115 V, 1.12 W, 230 V, 1.95 W, 400 V, 2.27 W, 480 V
