Schneider Electric MH31002P07F2200 Servo Motor 5.67 Nm, 6000 RPM, IP65/IP67, 6.4 kg
Schneider Electric MH31002P07F2200 Servo Motor 5.67 Nm, 6000 RPM, IP65/IP67, 6.4 kg
- MPN: MH31002P07F2200
- PPN: SCH-MH31002P07F2200
- UNSPSC: 39121021
Spec sheet
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$2336.26/ EA
Description
Engineered for precision and reliability, the MH3 servo motor from Schneider Electric offers exceptional performance with a continuous power output of 2270 W and a maximum mechanical speed of 6000 rpm. Its robust design features an IP65/IP67 rating, ensuring protection against dust and water, making it suitable for demanding environments. With a nominal torque of 5.67 N.m and a peak stall torque of 18 N.m, this three-phase motor is equipped with a holding brake for enhanced control, while its multiturn SinCos Hiperface encoder provides accurate speed feedback. Weighing in at 6.4 kg and designed with a standard mounting flange, the MH3 is compatible with the PacDrive 3 range, making it an ideal choice for various automation and motion control applications.
Specifications
Physical Attributes
- Motor Flange Size
- 100 mm
Shaft Length40 mm
Complementary Attributes
- Maximum Radial Force FR
- 990 N 1000 rpm, 790 N 2000 rpm, 690 N 3000 rpm, 620 N 4000 rpm, 580 N 5000 rpm
- Maximum Current IRMS
- 17.5 A
- Maximum Operational Altitude
- 3000.0 m
- Minimum Operational Altitude
- 0.0 m
Maximum Ambient Air Temperature For Operation60.0 °C
Maximum Mechanical Speed6000 rpm
Minimum Ambient Air Temperature For Operation-20.0 °C
Maximum In Rated Current4.1 A
Important Information Attributes
- Persona Type Ids
- EU, OM
- Inertia
- 0.49 kg.cm² of brake, 6.28 kg.cm² of motor
- Nominal Torque
- 5.67 N.m LXM52 4.81 mA, 115 V, three phase, 5.33 N.m LXM52 4.58 mA, 230 V, single phase, 4.67 N.m LXM52 4.1 mA, 400 V, three phase, 4.2 N.m LXM52 3.73 mA, 480 V, three phase, 5.67 N.m LXM62 4.81 mA, 115 V, single phase, 5.33 N.m LXM62 4.58 mA, 230 V, single phase, 4.67 N.m LXM62 4.1 mA, 400 V, three phase, 4.2 N.m LXM62 3.73 mA, 480 V, three phase
- Carbon Footprint Of The End Of Life Phase C1 To C4
- 0.5 kg CO2 eq., 0.4580012847
- Carbon Footprint Of The Manufacturing Phase A1 To A3
- 41 kg CO2 eq., 40.6051153285
- Local Data Status
- Publishable
- Device Type
- Motion - drive & motor
- Traceability
- Yes
- Average Life Duration
- 15 year(s)
- Scope Perimeter
- At least in Europe
- Reach Full Compliance Status
- Reference contains Substances of Very High Concern above the threshold
- Reach Compliance Directive
- Reference contains Substances of Very High Concern above the threshold
- ROHS EUR Status
- Compliant with Exemptions
- ROHS EUR Full Compliance Status Id
- PRO_ACTIVE_COMPLIANCE
- Green Premium Status For Reporting
- Green Premium product
- Without Single Use Plastic
- No
- Return Indicator
- Y
- Function Option Id
- ADVANCED
- Market Segmentation Id
- INDUSTRIAL
- Brake Pull In Power
- 12 W
- Circle Diameter Of The Mounting Holes
- 115 mm
- Continuous Stall Torque
- 6 N.m, 115...480 V, three phase
- Derating Temperature Scale
- 80.0 °C
- Holding Brake
- with
- Maximum Operational Altitude
- 3000.0 m
- Minimum Operational Altitude
- 0.0 m
- Mounting Holes Diameter
- 9 mm
- Peak Stall Torque
- 18 N.m, 115...480 V, three phase
- Product Or Component Type
- servo motor
- Second Shaft
- without second shaft end
- Shaft End
- smooth shaft
- Stator Electrical Time Constant
- 5 ms
- Stator Resistance
- 1.97 Ohm
- Temperature Copper Hot
- 135 °C
- Total Lifecycle Carbon Footprint
- 2 212 kg CO2 eq.
- Relationship Type
- Compatible relationship
- Pep Verification Date
- 2020-08-01
- Type Of Verification For The Pep
- Independent internal review
- Functional Unit Unit
- unit
- Product Manager
- FABIEN GAULT
Persona Type NamesEnd User, Original Equipment Manufacturer
Nominal Speed1000 rpm LXM52 4.81 mA, 115 V, single phase, 2000 rpm LXM52 4.58 mA, 230 V, single phase, 4000 rpm LXM52 4.1 mA, 400 V, three phase, 5000 rpm LXM52 3.73 mA, 480 V, three phase, 1000 rpm LXM62 4.81 mA, 115 V, single phase, 2000 rpm LXM62 4.58 mA, 230 V, single phase, 4000 rpm LXM62 4.1 mA, 400 V, three phase, 5000 rpm LXM62 3.73 mA, 480 V, three phase
Carbon Footprint Of The Distribution Phase A40.7251030657, 0.7 kg CO2 eq.
Carbon Footprint Of The Installation Phase A50.0430746336, 0 kg CO2 eq.
Carbon Footprint Of The Use Phase B2 B3 B4 B62 170 kg CO2 eq., 2169.7253379421
Local Publishable Date2026-01-12
ServiceabilityYes
Field Service DivisionIDIBS
Legacy WEEE ScopeOut
EOLI Availability DisplayNo need of specific recycling operations
Reach Full Compliance Status IdCONTAINS_SVHC
ROHS EUR In ScopeNo
ROHS EUR Full Compliance StatusPro-active compliance (Product out of EU RoHS legal scope)
China ROHS In ScopeYes
With Recycled CardboardYes
Product Contributes To Saved And Avoided EmissionsNo
WD Status5 - INITIALIZED WITH DataSCAN OK (Migration)
Function OptionAdvanced
Market SegmentationIndustrial
Centring Collar Diameter95 mm
Continuous Stall Current5.04 A
Derating Altitude Scale80.0 m
Device Short NameMH3
Holding Torque5.5 N.m
Minimum Ambient Air Temperature For Operation-20.0 °C
Motor Figures480.0 V
Package Weight Lbs5.62 kg
Product AvailabilityNon-Stock - Not normally stocked in distribution facility
ReturnabilityYes
Shaft Diameter19 mm
Sizing ReferenceMH31002P
Stator Inductance8.24 mH
Sustainable PackagingNo
Torque Constant1.19 N.m/A 120 °C
Maximum In Rated Current4.1 A
Pep CodeENVPEP111002EN
PCR VersionPCR-ed3-EN-2015 04 02
Functional Unit DescriptionTo coordinate and synchronize motion control up to 117W during 10 years and a 70% use rate.
Product Kit IdentifierN
Environment Attributes Main
- EU ROHS Directive
- Compliant By Exemption, Pro-active compliance (Product out of EU RoHS legal scope)
- Take Back
- No
- China ROHS Regulation
- X
- Carbon Footprint
- 2211.5566322545
- IP Degree Of Protection
- IP65 standard
- Packaging Without Single Use Plastic
- No
- Pep Code
- ENVPEP111002EN
- PCR Version
- PCR-ed3-EN-2015 04 02
ROHS Exemption InformationYes
Recycled Metal Content At Cr Level0 %
Mercury FreeYes
Environmental DisclosureENVPEP111002EN
Packaging Made With Recycled CardboardYes
Reach RegulationReference contains Substances of Very High Concern above the threshold
Pep Verification Date2020-08-01
Type Of Verification For The PepIndependent internal review
General Attributes
- Product Or Component Type
- servo motor
Output Attributes
- Nominal Output Power
- 0.59 W, 115 V, 1.12 W, 230 V, 1.95 W, 400 V, 2.27 W, 480 V
