Schneider Electric NSYMM13SB Plain Mounting Plate 150mm x 300mm Galvanised Steel, 1.5mm Thick, 0.402kg
- MPN: NSYMM13SB
- PPN: SCH-NSYMM13SB
CAD
$22.55
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Designed for versatility and robust performance, this plain mounting plate is an essential accessory for various applications within the PanelSeT range by Schneider Electric. Constructed from durable galvanised sheet steel, it features a metallic surface finish and measures 150mm in height and 300mm in width, providing ample space for mounting components securely at the bottom of an enclosure. With a thickness of 1.5mm and a weight of just 0.402 kg, this mounting plate is engineered for efficiency, allowing for easy installation using self-tapping screws. Its reliable design supports a permanent permissible load of up to 2.25 kg, making it a dependable choice for your mounting needs.
