Burndy YA8C2LN HYLUGTM Non-Insulated Terminal Connector, Copper, #8 AWG, 35 kV, 1/2 Inch Stud
- MPN: YA8C2LN
- UPC: 781810044612
- PPN: BUR-518640
CAD
$35.09
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Cu Comp Terminal Code Cond, Bvl Entry, 2 Hole/W/InspWindow, #8 AWG Str Code, 23 Navy, 600 V-35 kV, 1/2" Stud, 1.75" Spacing, Std bbl, Red, 49 Index.
Documentation & Downloads
Specifications
Dimensions
- Dimension - B Length fraction
- 7/16 in
- Dimension - Bolt Hole Size inch
- 0.52 in
- Dimension - Hole Size mm
- 14 mm
- Dimension - Length Overall inch
- 3.75 in
- Dimension - Outside Diameter inch
- 0.27 in
- Dimension - Strip Length inch
- 7/16
- Dimension - Z inch
- 0.64 in
Dimension - B Length inch0.44 in
Dimension - D inch1.26 in
Dimension - L Length Overall mm95 mm
Dimension - N inch0.62 in
Dimension - Pad Width inch0.83 in
Dimension - Stud Size inch1/2
Physical Attribute - Tongue AngleStraight
Certifications and Compliance
- Certification - CSA Approved
- Yes
- Certification - UL Recognized
- No
- Standards - RoHS Compliance Status
- CM
Certification - ETLNo
Certification - cULusNo
UL ListedYes
Conductor Related
- Conductor - Copper Str Navy Size
- 23 (7) Navy
- Conductor - Copper Str Size
- 8 AWG
- Conductor - Material
- Copper
Conductor - Copper Str Navy Size Range23 (7) Navy
Conductor - Copper Str Size Range8 AWG
General
- Application
- For Code Conductor
- Connector Type
- Terminal
- Feature - Barrel Style
- Chamfered
- Material
- Copper
- Plated
- Y
- Sub Brand
- TERMINALS, HYLUG
- Type
- Standard Barrel, Tin Plated
Color CodeRed
Die Index49
Feature - Barrel TypeStandard
Physical Attribute - Number of Holes2
Plating TypeTin - Electro Plated
Trade NameHYLUG™
UPC781810044612
Electrical Ratings
- Rating - KVA
- 35 kV
- Voltage - Maximum
- 35000
Rating - Minimum Voltage600
Logistics
- Minimum Pack Quantity
- 1
