Schneider Electric NSYSTMP22120 Perforated Mounting Plate 1200 mm x 225 mm Galvanized Steel
- MPN: NSYSTMP22120
- PPN: SCH-NSYSTMP22120
CAD
$128.43
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
This perforated mounting plate from Schneider Electric is designed for use in electrical enclosures, measuring a generous 1200 mm in width and 225 mm in height. Constructed from galvanized steel, it ensures durability and resistance to corrosion, making it suitable for a variety of multi-purpose applications. The mounting plate features cut-out dimensions of 11 x 26 mm and is equipped for easy installation with fixing elements on the structure, providing a reliable solution for your electrical needs. With an 18-month warranty, this product exemplifies quality and performance, making it an essential accessory for any electrical setup.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Italy
- Width
- 43.62 in
Height8.86 in
Important Information Attributes
- Persona Type Ids
- LC, OM, OM8, PB, SI
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- Device Composition
- 1 mounting plate, fixing elements
- Local Data Status
- Publishable
- Return Indicator
- N
- Stock Policy
- 2
- Scope Perimeter
- At least in Europe
- Reach Full Compliance Status
- Free of Substances of Very High Concern above the threshold
- Reach Compliance Directive
- Free of Substances of Very High Concern above the threshold
- Rohs Eur Status
- Compliant
- Rohs Eur Full Compliance Status
- Compliant
- China Rohs Label
- 1
- Without Single Use Plastic
- No
- Tier Id
- 2
- Function Option Id
- STANDARD
- Product Kit Identifier
- N
- Device Application
- multi-purpose
- Material
- steel
- Product Availability
- Non-Stock - Not normally stocked in distribution facility
- Quantity Per Set
- set of 1
- Returnability
- No
- Sustainable Packaging
- No
- Warranty In Months
- 18
- Height Nominal
- fixing centers: 200 mm
- Width Nominal
- nominal: 1200 mm
Persona Type NamesContractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, System Integrator
Market SegmentationCommercial, Industrial
Enclosure Nominal Dimensions-, -
Local Publishable Date2025-12-11
Stocking FlagY
Weee ScopeOut
Eoli Availability DisplayNo need of specific recycling operations
Reach Full Compliance Status IdNOT_CONTAINING_SVHC
Rohs Eur In ScopeNo
Rohs Eur Conformity Date1916
China Rohs In ScopeNo
With Recycled CardboardNo
Product Contributes To Saved And Avoided EmissionsNo
Tier2
Function OptionStandard
Cut Out Dimensions11 x 26 mm
Fixing Modeby fixing element - on structure
Mounting Plate DescriptionTelequick perforated
Product Or Component Typemounting plate
RangePanelSeT
Surface Finishzinc coated
Accessory Separate Part Categorymounting accessory
Pep CodeENVPEP2202003EN
Height Useful225 mm
Width Real1108 mm
Environment Attributes Main
- China Rohs Regulation
- Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
- Reach Free Shvc
- Yes
- Toxic Heavy Metal Free
- Yes
- Environmental Disclosure
- ENVPEP2202003EN
- Packaging Made With Recycled Cardboard
- No
- Reach Free Of Svhc
- Yes
- Pep Code
- ENVPEP2202003EN
Take BackNo
Recycled Metal Content At Cr Level0 %
Mercury FreeYes
Eu Rohs DirectiveCompliant
Packaging Without Single Use PlasticNo
Reach RegulationFree of Substances of Very High Concern above the threshold
General Attributes
- Product Or Component Type
- mounting plate
ETIM
- ETIM 8
- EC000213
ETIM 9EC000213
Contractual Warranty Attributes
- Warranty Period
- 18 months
Warranty18 months
