Weidmuller 4157440000 PF RS 80 OR 2000MM
- MPN: 4157440000
- PPN: WDM-4157440000
CAD
$36.01
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Electronics housings, RS 80 orange, Extruded profile, Width: 84 mm
Documentation & Downloads
Specifications
System Characteristics
| Version | Extruded profile |
|---|---|
| PCB thickness | 1.6 mm |
| Cross-connection | No |
| Protection degree | IP20 |
| Number of PCBs per module | 1 |
|---|---|
| Tolerance for the PCB shape | ±0.2 |
| Contact to terminal rail | No |
| Encapsulation option | No |
Approvals
| ROHS | Conform |
|---|
Dimensions And Weights
| Length | 2,000 mm |
|---|---|
| Width | 84 mm |
| Height | 15.7 mm |
| Net weight | 210 g |
| Length (inches) | 78.74 inch |
|---|---|
| Width (inches) | 3.307 inch |
| Height (inches) | 0.618 inch |
Material Data
| Insulating material | PVC |
|---|---|
| Colour chart (similar) | RAL 2000 |
| UL 94 flammability rating | V-0 |
| Storage temperature, max. | 70 °C |
| Operating temperature, min. | -50 °C |
| Temperature range, installation, min. | -25 °C |
| Colour | orange |
|---|---|
| Comparative Tracking Index (CTI) | ≥ 600 |
| Storage temperature, min. | -25 °C |
| Max. relative humidity during storage | 80 % |
| Operating temperature, max. | 60 °C |
| Temperature range, installation, max. | 60 °C |
Classifications
| ETIM 6.0 | EC002779 |
|---|---|
| eClass 9.0 | 27-18-27-90 |
| eClass 10.0 | 27-18-27-92 |
| ETIM 7.0 | EC002779 |
|---|---|
| eClass 9.1 | 27-18-27-90 |
| UNSPSC | 30-21-18-01 |
Notes
| Descriptive text technical data | 3 heights are available for the cover profile and the end plates:TS mounting without cover: TS 32 = 45 mm, TS35x7.5 = 40.5 mmTS mounting with low cover: TS 32 = 72 mm, TS 35x7.5 = 67.5 mmTS mounting with high cover: TS 32 = 91 mm, TS 35x7.5 = 86.5 mmDirect mounting, without/low/high cover: 17 / 44 / 63 mmDimensions of the PCB:Thickness: 1.6 (±0.2) mm, width: 67.8 (+0.2) mmDimension of the RS section = length of the printed circuit board – 4.5 mmDimension ADP section = PCB length - 2 mmExample:PCB length 160 mm, RS section = 155.5 mm, ADP section = 158 mm |
|---|
