Telemecanique Sensors XMLK010B2C21 Pressure sensor, XMLK, pressure range 0 to 10 bar, output 4-20 mA, G1/4A, DIN connector
- MPN: XMLK010B2C21
- PPN: TES-XMLK010B2C21
CAD
$149.22
/ EA
Available to Order from Manufacturer
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Pressure sensor, XMLK, pressure range 0 to 10 bar, output 4-20 mA, G1/4A, DIN connector
Documentation & Downloads
Specifications
Key Specifications
| Indivisible sale quantity | 1 |
|---|
| Commercial status | Commercialised |
|---|
Complementary
| Materials in contact with fluid | Ceramic nitrile (NBR) stainless steel type AISI 303 |
|---|---|
| Protection type | Load short-circuit reverse polarity |
| Response time on output | < 5 ms |
| Accuracy | 0.1 % of the measuring range |
| Drift of the zero point | +/- 0,03 % of measuring range/°K |
| Scale type | Fixed differential |
| Operating position | Any position |
|---|---|
| Electromagnetic compatibility | Electrostatic discharge immunity test conforming to IEC 61000-4-2 8 kV air, 6 kV contact, susceptibility to electromagnetic fields conforming to IEC 61000-4-3 10 V/m 80...1000 MHz, electrical fast transient/burst immunity test conforming to IEC 61000-4-4 2 kV, 1.2/50 µs shock waves immunity test conforming to IEC 61000-4-5 500 V 12 Ohm, 1 kV 42 Ohm, radiated RF fields conforming to IEC 61000-4-6 10 V 0.15...80 MHz, immunity to magnetic fields conforming to IEC 61000-4-8 30 A/m 50 Hz |
| Measurement accuracy | +/- 1 % de la plage de mesure |
| Drift of the sensitivity | +/- 0,04 % of measuring range/°K |
| Repeat accuracy | +/- 1 % de la plage de mesure |
Environment
| Standards | CE IEC 61326-2-3 |
|---|---|
| Protective treatment | TC |
| Shock resistance | 25 gn for 11 ms conforming to IEC 60068-2-27 |
| NEMA degree of protection | NEMA 4 |
| Product certifications | CSA C22-2 No 14 RCM UL 508 |
|---|---|
| Vibration resistance | 20 gn (f = 9-2000 Hz) conforming to IEC 60068-2-6 |
| IP degree of protection | IP65 conforming to IEC 60529 |
Main
| Range of product | Telemecanique Pressure sensors XM |
|---|---|
| Pressure sensor type | Pressure transmitter |
| Electrical circuit type | Control circuit |
| Controlled fluid | Air (0-80 °C), fresh water (0-80 °C) |
| Electrical connection | 1 male connector EN 175301-803-A (ex DIN43650) 4 pins |
| Current consumption | 20 mA |
| Analogue output function | 4...20 mA, 2-wire |
| Type of packing | Individual |
| Product or component type | Electronic pressure sensors |
|---|---|
| Pressure sensor name | XMLK |
| Local display | Without |
| Fluid connection type | G 1/4A (male) conforming to DIN 3852-E |
| Rated supply voltage (Us) | 24 V DC SELV (voltage limits: 8-33 V) |
| Type of output signal | Analogue |
| Quantity per set | Set of 1 |
