Telemecanique Sensors XMLK200P2C23 Electronic pressure sensors, Pressure sensors XM, sensor XMLK, 0...200 PSI, 1/4NPT, 4...20 mA, DIN, set of 1
Telemecanique Sensors XMLK200P2C23 Electronic pressure sensors, Pressure sensors XM, sensor XMLK, 0...200 PSI, 1/4NPT, 4...20 mA, DIN, set of 1
- MPN: XMLK200P2C23
- PPN: TES-XMLK200P2C23
- UNSPSC: 39122210
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$149.22/ EA
Specifications
Environment
- Product Certifications
- EAC || CSA C22.2 No 14 || UL 508 || RCM
- Standards
- CE || EN/IEC 61326-2-3
- Vibration Resistance
- 20 gn 9-2000 Hz) EN/IEC 60068-2-6
- Nema Degree Of Protection
- NEMA 4
- Protective Treatment
- TC
Ambient Air Temperature For Operation0-80 °C
Shock Resistance25 gn 11 ms EN/IEC 60068-2-27
Ip Degree Of ProtectionIP65 conforming to EN/IEC 60529
Ambient Air Temperature For Storage-25-80 °C
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Rohs Exemption Information
- Yes
- Reach Regulation
- Free of Substances of Very High Concern above the threshold
- Reach Free Of Svhc
- Yes
Mercury FreeYes
California Proposition 65WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Eu Rohs DirectivePro-active compliance (Product out of EU RoHS legal scope)
Complementary
- Accuracy
- 0.1 % of the measuring range
- [Uimp] Rated Impulse Withstand Voltage
- 0.5 kV
- Drift Of The Zero Point
- +/- 0.03 % of measuring range/°K
- Materials In Contact With Fluid
- stainless steel type AISI 303 || nitrile (NBR) || ceramic
- Net Weight
- 0.11 kg
- Mechanical Durability
- 10000000 cycles
- Measurement Accuracy
- +/- 1 % of the measuring range
- Drift Of The Sensitivity
- +/- 0.04 % of measuring range/°K
- Destruction Pressure
- 600 psi
- Pressure Setting Range
- 0-200 psi
Diameter36 mm
Repeat Accuracy+/- 1 % of the measuring range
Electromagnetic Compatibilityelectrostatic discharge immunity test EN/IEC 61000-4-2 8 kV air, 6 kV contact || susceptibility to electromagnetic fields EN/IEC 61000-4-3 10 V/m 80...1000 MHz || electrical fast transient/burst immunity test EN/IEC 61000-4-4 2 kV || 1.2/50 µs shock waves immunity test EN/IEC 61000-4-5 500 V 12 Ohm, 1 kV 42 Ohm || radiated RF fields EN/IEC 61000-4-6 10 V 0.15...80 MHz || immunity to magnetic fields EN/IEC 61000-4-8 30 A/m 50 Hz
Length65.5 mm
Scale Typefixed differential
Operating Positionany position
Protection Typereverse polarity || load short-circuit
Maximum Permissible Accidental Pressure400 psi
Response Time On Output< 5 ms
Specifications
- Pressure Sensor Type
- pressure transmitter
- Range Of Product
- Telemecanique Pressure sensors XM
- Pressure Sensor Size
- 200-200 psi
- Type Of Packing
- individual
- Pressure Sensor Name
- XMLK
- Fluid Connection Type
- 1/4" - 18 NPT (male)
- Controlled Fluid
- air 0-80 °C) || fresh water 0-80 °C)
- Electrical Circuit Type
- control circuit
Type Of Output Signalanalogue
Electrical Connection1 male connector EN 175301-803-A (ex DIN43650) 4 pins
Product Or Component Typeelectronic pressure sensors
Local Displaywithout
Current Consumption< 20 mA
Analogue Output Function4...20 mA, 2-wire
Quantity Per Setset of 1
[Us] Rated Supply Voltage24 V DC SELV 8-33 V)
