Homac ABW 6500-58 C Quick-Disconnect Transformer Connector
- MPN: ABW 6500-58 C
- UPC: 783786689835
- PPN: T-B-ABW 6500-58 C
CAD
$111.39
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 6-500, length 8-1/18 inch, boot no. SB 2157 stud size 5/8 inch, outlets 6, Oxide Inhibitor
Documentation & Downloads
Specifications
North American Specifications (UNSPSC)
- UNSPSC
- 39121443 Electrical underground bus connector
- Brand Name
- Homac
- Special Features
- In-Line Bar Series. Dual Rated for Aluminum and Copper Conductors. High Strength Aluminum Alloy maintains constant bolting pressure on Conductors. Quick Disconnectability for easy removal from transformer secondary studs. Ball-bottom screws ensure maximum conductor contact pressure and break up interstrand oxides.
- Standard
- ANSI C119.4
- Conductor Range
- 6 to 500 kcmil
- Material
- Aluminum
IGCC4663 Electrical underground bus connector
TypeQuick-Disconnect Transformer Connector
ApplicationStud Mount Transformer Connector
ConnectionMechanical
Number Of Conductors6
InsulationInsulating Boot
Packaging
- Outer Quantity
- 25
- Weight Uom
- 0.78 lbs. Each
Outer Dimensions (inches)1x1x1
