Dragon Tooth 204212 RING TERM CU 12-4 AWG 1/4 BOLT
- MPN: 204212
- UPC: 786210867632
- PPN: T-B-204212
- UNSPSC: 39121432
CAD
$3.08
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Insulation Piercing Magnet Wire Ring Terminal, Length 1.58 Inches, Width .50 Inches, Length of Teeth .61 Inches, Width of Teeth .53 Inches, Stud Size 1/4 Inch, Wire Range #12 AWG - #4 AWG 10,380 Circular Mil Area - 52,480 Circular Mil Area, Copper Alloy, Tin Plated
Specifications
Additional Information
| Application | For aluminum to copper, aluminum to aluminum or copper to copper magnet wire connections. |
|---|---|
| Effective Date | 19710507 |
| Product Name | ELECTRICAL TERMINAL |
| Special Functions | Designed to penetrate magnet wire insulation during application, eliminating the need for stripping, brazing, welding or other methods of joining magnet wire. |
| Sub Brand / Label | Dragon Tooth |
| Brand / Label | Sta-Kon |
|---|---|
| Material | Copper |
| Product Type | Ring Terminal |
| Standards | UL E9809 |
Ordering
| Country of Origin | United States (US) |
|---|
| Selling Unit of Measure | each |
|---|
Classifications
| WEEE Category | Product Not in WEEE Scope |
|---|
| IDEA Granular Category Code (IGCC) | 4603 >> Electrical terminals |
|---|
