Pass & Seymour PLS1820FW Series 18 In-Line Connectors, 6.8 Inch Length, Wire Acceptance #6-4/0
- MPN: PLS1820FW
- UPC: 785007255218
- PPN: P-S-PLS1820FW
CAD
$64.95
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Series 18 In-Line Connectors, 6.8 Inch Length, Wire Acceptance #6-4/0
Features
- Interchangeable with Canadian CAM devices from other manufacturers. Ball nose design achieves NEMA 3R, 4 rating. Designed specifically for Sea Way cable. Accepts #6 through 4/0 size wire.
- Double set screws for premium wire retention. Locking screw prevents contact from rotating inside housing.
Documentation & Downloads
Specifications
Key Specifications
- Length
- 6.8 in
- Color
- White
- Standard
- UL
- Wire Size
- 2/0
- Voltage
- 600.0 V
- Number of Poles
- Single Pole
- Application Sector
- Industrial
- Special Features
- Interchangeable with Canadian CAM devices from other manufacturers. Ball nose design achieves NEMA 3R, 4 rating. Designed specifically for Sea Way cable. Accepts #6 through 4/0 size wire. Double set screws for premium wire retention. Locking screw prevents contact from rotating inside housing.
Country of OriginMexico
Product LinePass & Seymour
StandardcUL
StandardcCSAus
Amperage400.0 A
Application SectorCommercial
NEMA RatingNEMA 3R and 4 for indoor applications
Environmental ConditionsOperating Temperature: Maximum continuous +75°C, minimum -40°C without impact: Flammability UL94 V2: Enclosure: NEMA Type 3R and 4
