Mersen STP1000YPVM Surge-Trap Pluggable SPD, 1000V, 50 kA, 3-Pole, DIN Rail Mountable
- MPN: STP1000YPVM
- UPC: 782001419721
- PPN: FER-STP1000YPVM
CAD
$1411.17
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Surge-Trap® Pluggable Surge Protective Device (SPD) is a no-fuse, fail-safe surge suppressor featuring Mersen’s patented TPMOV® technology inside. UL 1449 4th Edition approved, it is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator, and a small footprint. A remote indicator option provides status to critical control circuitry. The Surge-Trap Pluggable SPD has a high short circuit rating and a thermally protected MOV, which eliminates the need for additional overcurrent protection devices.
Features
- Easy installation or retrofit
- DIN-rail mountable
- Fail-safe, self-protected design
- Remote indicator
- Visual indicator
- IP20 finger-safe design
- Small footprint
- No additional overcurrent protection devices required
- Easy to replace modules
- 2-year warranty
Documentation & Downloads
Specifications
Key Specifications
- Sell Pack Height
- 2.75 in
- Product Length
- 3.58 in
- Wiring range
- #6 to #14 AWG
- ROHS Compliant
- Yes
- Product Height
- 2.7 in
- Product Width
- 2.1 in
- Sell Pack Length
- 4.88 in
- AC or DC
- DC
- Nominal Discharge Current (In) (8/20)
- 20 kA
- Indication System Type
- Microswitch
- Max Discharge Current : Imax (8/20)
- 50 kA per phase
- Short Circuit Current Rating (SCCR)
- 200 (most models) kA
- Number of Poles
- 3-pole
Product Weight1.15 lb
Housing MaterialPET (Polyethelene Terphthalate)
Installation MountingDIN Rail
Nominal Operating Volt Rating (Un)1000 V
Number of Wires3 Wire
Sell Pack Width2.88 in
Connection/Terminal TypeBox
Sell Pack Quantity1 Each
System ConfigurationPhotovoltaic
UL SPD TypeType 1 Component Assembly
MOV Response Time<25 ns
Indication SystemYes
