Homac Z 5033-1 SL/B Stud-Mount Transformer Connector
- MPN: Z 5033-1 SL/B
- UPC: 078378676233
- PPN: T-B-Z 5033-1 SL/B
CAD
$153.66
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Zeebar Aluminum Transformer Connector, #12 - 350 kcmil, Aluminum-Copper, Stud 1 inch, Eight Conductor
Documentation & Downloads
Specifications
Packaging
- Outer Quantity
- 20
- Weight Uom
- 1.6 lbs. Each
Outer Dimensions (inches)13.875x8.625x17.875
North American Specifications (UNSPSC)
- UNSPSC
- 39121443 Electrical underground bus connector
- Brand Name
- Homac
- Special Features
- Compact Zeebar design halves cantilever stress and doubles cable capacity. Easy to install with all screws on top. A 5/16 inch hex wrench does it all - including the street light option. Fits both 5/8 and 1 inch studs. Dual Rated to accept Copper or Aluminum Conductors. Ball-Bottom screws ensure maximum conductor contact pressure and break up interstrand oxides.
- Standard
- ANSI C119.4
- Connection
- Mechanical
- Number Of Conductors
- 8
IGCC4663 Electrical underground bus connector
TypeStud-Mount Transformer Connector
ApplicationCompact Secondary Transformer Connector with a Street Light Outlet
Size5-3/4 inch X 2-7/8 inch
Conductor Range12 to 350 kcmil
MaterialAluminum
