Bryant 60303D Industrial Grade Toggle Switch, 60A 600V AC, 3 Pole, NEMA 3R Enclosure
- MPN: 60303D
- UPC: 781786631786
- PPN: HBL-60303D
- UNSPSC: 39121521
CAD
$496.06
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Switches and Lighting Controls, Industrial Grade, Toggle Switches, Manual Motor Controllers, Three Pole, 60A 600V AC, Side Wired Only, Black, With NEMA 3R Enclosure
Features
- Toggle
- Manual Motor Controllers
- Three Pole
- 60A 600V AC
- Side Wired Only
- Standard Product
Documentation & Downloads
Specifications
Key Specifications
- Number of Poles
- 3 Pole
- General Literature Asset 1 Display Text
- General Literature - Motor Controllers and Disconnects
- Current / Amperage Rating
- 60 A
- Standards - RoHS Compliance Status
- CM
- Voltage Rating Description
- 600V AC kV
- Application
- Red Slide
- Display Size
- Standard Sized Product
- Environmental Conditions
- Indoor and Outdoor
- Number Of Poles
- 3 Pole
- Operating Temperature
- Minimum Continuous -40 Deg C without Impact
- Style
- Standard Duty
- Wattage
- 36000
- Description - Invoice
- 60A 600V 3P DISCSW W/NEMA 3R
- Harmonization Code
- 8536509901
- MSDS Flag
- No
- Sub Class Code
- A16A240
- Current Rating
- 60 A
- Base Unit of Measure
- EA
- Carton - Gross Weight per Pack
- 10.05 lb.
- Carton - Pack Description
- Carton
- Carton - Total Units
- 4 EA
- Each - Pack Description
- Each
Special FeaturesStandard Product
Country of OriginPuerto Rico
Width5.000 in
Voltage Rating600V AC kV
Amperage Rating60 A
ConnectivityPressure Terminal Screws
Enclosure TypeNEMA 3R
Load CapacityInductive
Operating Cycles10,000 Cycles Minimum
PhaseThree Phase
TypeDisconnect Switches
Class CodeA16
Freight Class Code06168002
Image Actual Or RepresentativeA
Replaced Catalog Number60303
Material - Mounting HardwareScrew Mounting
SeriesNon-Fused
BOX SIZE10.600x12.000x10.100 (in)
Carton - Number of Sub Packs4
Carton - SCC-14 Next Lower Level Sub Pack781786631786
Case Weight9.650 lb.
Lowest Level UOMEach
Certifications
- EU RoHS Indicator
- No
