Schneider Electric LAD4VG TeSys Deca Suppressor Module, Varistor, 50-127V AC, IP2X, 0.012 kg

MPN: LAD4VG
PPN: SCH-LAD4VG

If you can't find the product or are unsure which one you need, please use the Product Selector tool below

$71.02

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

TeSys Deca suppressor module, for LC1D09-D38, LC1DT20-DT40 contactors and CAD control relays. To be used with 50-127V AC control circuit voltage, it provides a varistor protection limiting the transient voltage to 2 Uc max. Clip-on side mounting, overall size of the contactor is unchanged.

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	France, United States

Complementary Attributes

Maximum Peak Voltage	2 Uc

Important Information Attributes

Persona Type Ids	EU, LC, OM, OM8, PB, SI
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Range Of Product	TeSys Deca, TeSys Deca control relay
Carbon Footprint Of The Distribution Phase [A4]	0.0014215986949429036, 0 kg CO2 eq.
Carbon Footprint Of The Manufacturing Phase [A1 To A3]	0.1 kg CO2 eq., 0.10814681892332789
Local Publishable Date	2026-06-30
Stocking Flag	Y
Serviceability	No
Field Service Division	PPIBS
Weee Product Category	5
Eoli Availability Display	No need of specific recycling operations
Reach Full Compliance Status Id	NOT_CONTAINING_SVHC
Rohs Eur In Scope	Yes
Rohs Eur Conformity Date	1926
China Rohs In Scope	No
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	1
Function Option	Standard
Compatibility Code	LAD4
Mounting Location	front
Product Availability	Stock - Normally stocked in distribution facility
Range	TeSys
Software Version	v5.9.4
Sustainable Packaging	Yes
Weee Label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Database Version	2022-01
Pcr Version	PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep	Independent internal review
Functional-unit Description	It provides a flywheel diode protection ensuring no transient overvoltage. Clip-on side mounting, overall size of the contactor is unchanged.
Functional-unit Unit	unit
Energy Model - Manufacturing [A1-a3]	Electricity Mix; Production mix; Low voltage; FR
Energy Model - Use [B6]	Electricity Mix; Production mix; Low voltage; FR
Recyclability Potential In %	20
Nbr. Of Units In Pkg.	1
Take-back	No
Customs Code	8533408070

Persona Type Names	End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, System Integrator
Market Segmentation	Commercial, Industrial
Certificate Agency	UL, CSA
Carbon Footprint Of The End-of-life Phase [C1 To C4]	0 kg CO2 eq., 0.035977487765089716
Local Data Status	Publishable
Return Indicator	Y
Stock Policy	1
Traceability	No
Weee Scope	In
Scope Perimeter	At least in Europe
Reach Full Compliance Status	Free of Substances of Very High Concern above the threshold
Reach Compliance Directive	Free of Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
China Rohs Label	1
Without Single Use Plastic	No
Tier Id	1
Function Option Id	STANDARD
Product Kit Identifier	N
Device Short Name	LAD4
Mounting Mode	by clips
Product Or Component Type	suppressor module
Returnability	Yes
Suppressor Technology	varistor (peak limiting)
Total Lifecycle Carbon Footprint	0.1 kg CO2 eq.
Pep Code	ENVPEP1112053EN
Pep Verification Date	2025-08-05
Psr Version	PSR-0005-ed2-2016 03 29
Data Source	extrapolated product
Functional-unit Quantity	1
Reference Lifetime In Y	20
Energy Model - Installation [A5]	Electricity Mix; Production mix; Low voltage; FR
Energy Model - End Of Life [C1-c4]	Electricity Mix; Production mix; Low voltage; FR
[Uc] Control Circuit Voltage	50...127 V AC
Package Weight(Lbs)	14.000 g
Warranty (In Months)	18

Environment Attributes Main

China Rohs Regulation	Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
Ambient Air Temperature For Storage	-40-80 °C, -40-80 °C
Take Back	No
Recycled Metal Content At Cr Level	0 %
Mercury Free	Yes
Environmental Disclosure	ENVPEP1112053EN
Ip Degree Of Protection	IP2XIEC 60529
Packaging Without Single Use Plastic	No
Reach Regulation	Free of Substances of Very High Concern above the threshold
Pep Verification Date	2025-08-05
Psr Version	PSR-0005-ed2-2016 03 29

Ambient Air Temperature For Operation	-25-55 °C, -25-55 °C
Product Compatibility	3P LC1D09...D384P LC1DT20...DT40, 4P LC1D098...D258, CAD32, CAD50
Reach Free Shvc	Yes
Toxic Heavy Metal Free	Yes
Carbon Footprint	0.1455459053833605
Eu Rohs Directive	Compliant
Packaging Made With Recycled Cardboard	Yes
Reach Free Of Svhc	Yes
Pep Code	ENVPEP1112053EN
Pcr Version	PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep	Independent internal review
