Blackburn TSL6E58 Threaded Stud Transformer Connector, 5/8-11 Thread, 650 Amps Max, 6 Positions
- MPN: TSL6E58
- UPC: 783786897322
- PPN: T-B-TSL6E58
CAD
$62.53
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Threaded Stud Transformer Connector - 5/8-11 Thread, 6 Positions, Wire Range #6 - 500 kcmil, use with LAC and LCU Lugs. Contains Oxide Inhibiting Compound. 650 Amps Maximum
Specifications
North American Specifications (UNSPSC)
- UNSPSC
- 39121408 Mechanical connectors
- Brand Name
- Blackburn
- Special Features
- Terminals have 3/8 inch Plated Steel Bolts with Captive Belleville Washers, Bus is Notched to Accept the Locking Boss on Type LAC Lugs.
- Connection
- Threaded Stud
- Conductor Range (Main/Primary)
- #6 Stranded to 500 kcmil
- Number of Conductors/Ports (Tap/Secondary)
- 6
IGCC4541 Mechanical connectors
TypeThreaded Stud Transformer Connector
ApplicationFor Use with Single Bolt LAC, LCN or CAL Lugs
Amperage Rating650 Amps Max
Conductor Range (Tap/Secondary)#6 Stranded to 500 kcmil
Packaging
- Outer Quantity
- 24
- Weight Uom
- 93.75 lbs. per 100
Outer Dimensions (inches)14x7.5x6.8
