Bryant RRD15BK Decorator Duplex Receptacle 15A 125V 2-Pole with 3-Wire Grounding
- MPN: RRD15BK
- UPC: 883778100130
- PPN: HBL-RRD15BK
- UNSPSC: 39121406
CAD
$2.91
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
tradeSELECT® Straight Blade Residential Grade, Decorator Duplex, 15A 125V, 2-Pole 3-Wire Grounding, 5-15R
Features
- Residential Grade
- Receptacles
- Decorator Duplex
- Standard Product
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- China
- Width
- 1.590 in
- Amperage Rating
- 15 A
- Color
- Black
- NEMA Rating
- 5-15R
- Number of Wires
- 3-Wire Grounding
- Special Features
- Standard Product
- Wattage
- 1875
- Voltage Rating Description
- 125 VAC
- Display Size
- Standard Sized Product
- Number Of Poles
- 2-Pole
- Description - Invoice
- RESI DUP RCPT, 15A 125V, DEC FACE, BK
- Harmonization Code
- 8536698000
- MSDS Flag
- No
- Current Rating
- 15 A
- Base Unit of Measure
- EA
- Carton - Gross Weight per Pack
- 1.300 lb.
- Carton - Pack Description
- Carton
- Carton - Total Units
- 10 EA
- Case Weight
- 26.850 lb.
- Lowest Level UOM
- Each
- Pallet Height
- 42.500 in
- Pallet Weight
- 1342.500 lb.
Current / Amperage Rating15 A
Standards - RoHS Compliance StatusCM
ApplicationResidential Receptacles
Environmental ConditionsIndoor Dry Unless Protected By Additional Means
Number of Poles2-Pole
PhaseSingle Phase
Voltage Rating125 VAC
Wire Size#14 AWG to #12 AWG
ConnectivityPush and Side Wire
Nema Rating5-15R
Number Of Wires3-Wire Grounding
Freight Class Code06168002
Image Actual Or RepresentativeA
Material - Mounting HardwareScrew Mounting
MaterialThermoplastic
BOX SIZE2.000x8.000x4.300 (in)
Carton - Number of Sub Packs10
Carton - SCC-14 Next Lower Level Sub Pack883778100130
Case - Total Units200 EA
Each - Pack DescriptionEach
Pallet - GTIN - Package70883778100139
Pallet Length48.000 in
Pallet Width40.000 in
Certifications
- EU RoHS Indicator
- Yes
