Balluff

Balluff BMF 07M-PS-D-2-S49-00,3 Tubular magnetic field sensors BMF 07M-PS-D-2-S49-00,3

Tubular magnetic field sensors BMF 07M-PS-D-2-S49-00,3
  • MPN: BMF 07M-PS-D-2-S49-00,3
  • PPN: BAL-BMF000K

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$181.67/ EA

Description

Tubular magnetic field sensors offer reliable and wear-free position detection. They are immune to vibration and sense through alloy and aluminum walls with no reduction in switching distance. At the same time they provide a significantly greater switching distance than inductive sensors of the same physical size. And can be flush mounted in steel.

Specifications

Specifications

Dimension
Ø 6.5 x 30 mm
Cable
PUR, 0.3 m
Mounting
Clamps
Switching output
PNP Normally open (NO)
Operating voltage Ub
10-30 VDC
IP rating
IP67
ConnectionM8x1-Male, 3-pin
ApplicationFlexible mounting, Switching distances > 20 mm possible
Housing materialBrass
Switching frequency10000 Hz
Ambient temperature-25-85 °C
Approval/ConformitycULus, CE, WEEE
