Blackburn Q 1 U 57 Uninsulated Aluminum Compression Splices 1/2 Inch, 2 Conductors, 15 lbs per 100
- MPN: Q 1 U 57
- UPC: 783786744671
- PPN: T-B-Q 1 U 57
CAD
$7.76
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Uninsulated Aluminum Service Entrance Compression Splices - 1/2 inch die series, Conductor A: Orange, 2 Solid, - Stranded, 4-6/1,7/1 ACSR, Conductor B: Orange, 2 Solid, - Stranded, 4-6/1,7/1 ACSR.
Documentation & Downloads
Specifications
North American Specifications (UNSPSC)
- UNSPSC
- 39121449 Wire or cable compression splice
- Brand Name
- Blackburn
- Special Features
- Solid center barriers and large chamfers. Easy cable installation. All splices are color-coded and marked with strip lengths, installation die codes, and compression locations for easy identification and installation. Constructed from Aluminum. Provides high conductivity. Prefilled with Oxide inhibitor to prevent oxidation and keep out moisture
- Connection
- Crimp/Compression
- Number Of Conductors
- 2
- Color
- Orange/Orange
IGCC4669 Wire or cable compression splice
TypeUninsulated Aluminum Service Entrance Compression Splices
ApplicationBasic, uninsulated splices for Service Etrances.
Conductor RangeSide A - #2 Solid, #4-6/1, 7/1 ACSR, Side B - #2 Solid, #4-6/1, 7/1 ACSR
MaterialAluminum
InsulationNone
Packaging
- Inner Quantity
- 100
- Outer Quantity
- 500
- Weight Uom
- 15 lbs. per 100
Inner Dimensions (inches)15.9x5.4x4.3
Outer Dimensions (inches)22x5.7x17.4
