Killark

Killark VFC-200 V Fixture Body Enclosed Gasketed 300W Max 5.25 Inch x 5.5 Inch x 3 Inch

V Fixture Body Enclosed Gasketed 300W Max 5.25 Inch x 5.5 Inch x 3 Inch
  • MPN: VFC-200
  • UPC: 783936730028
  • PPN: HBL-VFC-200
  • UNSPSC: 39111525

Spec sheet

Loading compare button...

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$198.40/ EA

Description

V Series - V Fixture Body - Enclosed And Gasketed Fixture Body - 300W Maximum

Features

  • Electrostatically applied epoxy/polyester finish
  • Modular design
  • Hubs are threaded for attachment to conduit
  • Set screws in pendant fixture
  • Copper-free aluminum (less than .004%)
  • Fixture bodies contain lamp receptacle and are threaded to accept globes, guards, and reflectors. These fixture bodies are designed for metallic boxes and mount directly to V Series splice boxes. They may also be mounted to VJ Series, VB Series, or other

Specifications

Specifications

Number Of Lamps
0
ARRA Compliant
Contact Manufacturer
Color
Gray
Height
3 in
Voltage Rating
120-277 VAC
Application
For use with V Series lighting.
Number of Lamps
0
Wattage
300 W
Description - Invoice
THREADED FIXTURE BODY 300W
Harmonization Code
9405999900
Lead Time
42 wk
Order Multiple
1 EA
Sub Class Code
D20D225
Light Source
Incandescent
Series
V Series
Carton - SCC-14 Next Lower Level Sub Pack
00783936730028
Pallet - GTIN - Package
50783936730023
Pallet Length
5.250 in
Pallet Width
5.500 in
Special FeaturesFixture bodies contain lamp receptacle and are threaded to accept globes, guards, and reflectors. These fixture bodies are designed for metallic boxes and mount directly to V Series splice boxes. They may also be mounted to VJ Series, VB Series, or other
Country of OriginMexico
Dimensions5.25 in x 5.5 in x 3 in
Length5.25 in
Width5.5 in
Frequency Rating50/60 Hz
TypeAluminum Fixture Body
Class CodeD20
Freight Class Code06316009
Image Actual Or RepresentativeA
MSDS FlagNo
Returnable IndicatorYes
Gross Weight with Packaging1.08
MaterialAluminum, Copper Free (less than 4/10 of 1%)
Base Unit of MeasureEA
Master Pack DescriptionEach
Pallet Height3.000 in
Pallet Weight1.080 lb.

Certifications

EU RoHS Indicator
Contact Manufacturer
