Killark VXFC-200 N34 Incandescent Fixture Body, 300W Max, 5.75 Inch, NEMA 3/4, Aluminum, Wall Bracket
- MPN: VXFC-200 N34
- UPC: 783936830506
- PPN: HBL-VXFC-200 N34
- UNSPSC: 39111525
CAD
$99.97
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
V Series - Incandescent Medium Base Fixture Body - NEMA 3, 4 /Class I,Div. 2 - 300 Watts Maximum
Features
- Electrostatically applied epoxy/polyester finish
- Modular design
- Hubs are threaded for attachment to conduit
- Set screws in pendant fixture
- Copper-free aluminum (less than .004%)
- Fixture bodies contain lamp receptacle and are threaded to accept globes, guards, and reflectors. These fixture bodies are designed for metallic boxes and mount directly to V Series splice boxes. They may also be mounted to VJ Series, VB Series, or other
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Mexico
- Hub Size
- 1/2"
- Application
- For use with V Series lighting.
- Finish
- Powder Epoxy Paint
- Height
- 5.25 in
- Length
- 5.75 in
- Number Of Lamps
- 0
- Type
- Aluminum Fixture Body
- Wattage
- 300 W
- Finish Type
- Powder Epoxy Paint
- Number of Lamps
- 0
- Class Code
- D20
- Freight Class Code
- 06316009
- Image Actual Or Representative
- A
- MSDS Flag
- No
- Returnable Indicator
- Yes
- Gross Weight with Packaging
- 1.14
- Material
- Aluminum, Copper Free (less than 4/10 of 1%)
- Base Unit of Measure
- EA
- Carton - SCC-14 Next Lower Level Sub Pack
- 00783936830506
- NAICS Code
- 3351222100
Dimensions5.75 in x 5.75 in x 5.25 in
Optic TypeGlass Globe - Clear
ColorGray
Frequency Rating50/60 Hz
Lamp TypeMedium Base
MountingWall Bracket
Special FeaturesFixture bodies contain lamp receptacle and are threaded to accept globes, guards, and reflectors. These fixture bodies are designed for metallic boxes and mount directly to V Series splice boxes. They may also be mounted to VJ Series, VB Series, or other
Voltage Rating120-277 VAC
Width5.75 in
Mounting TypeWall Bracket
ARRA CompliantContact Manufacturer
Description - Invoice200W V-SERIES CL.I DIV2 FIX CP
Harmonization Code9405994090
Lead Time42 wk
Order Multiple1 EA
Sub Class CodeD20D225
Light SourceIncandescent
SeriesV Series
BOX SIZE(in)
Master Pack DescriptionEach
