Burndy VTT4430 V Style Bolted Tee Connector, 5.63 Inch Length, for 2/0-4/0 AWG Copper Cables
- MPN: VTT4430
- UPC: 621945168985
- PPN: BUR-02004111
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
V Style Connectors
Documentation & Downloads
Specifications
Dimensions
- Dimension - Height inch
- 2.88 in
- Dimension - Length Overall inch
- 5.63 in
- Dimension - Width mm
- 49 mm
Dimension - L Length Overall mm143 mm
Dimension - Width inch1.94 in
Certifications and Compliance
- Certification - CSA Approved
- No
Standards - RoHS Compliance StatusUI
Conductor Related
- Conductor - Connection Combination
- Cable to Cable
- Conductor - Copper Solid Tap Range
- 2/0 AWG-4/0 AWG
- Conductor - Copper Str Run Range
- 750 kcmil-1000 kcmil
- Conductor - Copper Str Tap Range
- 1/0 -300 kcmil
Conductor - Copper Solid Tap2/0 AWG;3/0 AWG;4/0 AWG
Conductor - Copper Str Run750 kcmil;800 kcmil;850 kcmil;900 kcmil;1000 kcmil
Conductor - Copper Str Tap1/0 ;2/0 AWG;3/0 AWG;4/0 AWG;250 kcmil;300 kcmil
General
- Application
- Substation
- Material
- Copper Alloy
- One Wrench Installation
- Y
- Physical Attribute - Number of Tap Conductors
- 1
- Plating Type
- Unplated
- UPC
- 621945168985
Connector TypeT-Connector
Material - HardwareDURIUM™ Silicon Bronze
Physical Attribute - Number of Run Conductors1
PlatedN
TypeBolted Tees
UPC 12 Digit6219451689855
Electrical Ratings
- Rating - KVA
- 230 kV
Logistics
- Minimum Pack Quantity
- 1
