Brady THT-7-7576-3 VOID Indicating Metallized Polyester labels, 1.25" H x 2.75" W, 3000 Labels
- MPN: THT-7-7576-3
- UPC: 662820208211
- PPN: BRD-THT-7-7576-3
- UNSPSC: 55121612
CAD
$912.99
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
The B-7576 material is designed to leave a "VOID" footprint when the label is removed, the footprint also appears on the surface of the label so it cannot be reused.
Features
- Ideal for use in rating and serial plates that require high performance and evidence of label removal
- Use care when handling to maintain the VOID pattern
- For use in thermal transfer printers
Documentation & Downloads
Specifications
Key Specifications
- Applications
- General Identification; Security Identification
- Bulk Part
- Not a Bulk Part
- Compatible Surface Types
- High Surface Energy
- Enables Industry Compliance
- ASTM D 1000; ASTM G 155; UL Recognized
- For Use with Printer
- BBP®81 Label Printer; BradyPrinter i7100; BRADYPRINTER PR Plus Series Label Printer; THT 3" Core Printer
- Primary Noun, Basic Function
- Label
- Printer and Label Applications
- General Identification; Inspection Repair; Rating & Name Plates
- Printer Compatibility (Print)
- BBP12; i7100; i5100
- Quantity per Row
- 1
- Ribbon Series
- R6000HF
- Suggested Ribbon Series
- R4400; R6000 Halogen Free
- Total Qty per Pack
- 3000 Label(s) / Roll
- Trade Name
- Defender
- Adhesive Type
- Tamper-evident Acrylic
- Label Properties
- Heat Resistant Labels; Metallic Labels; Permanent Adhesive Labels; Tamper Evident Labels
- Material Properties
- Metallized; Tamper-evident
- SAP B-Number
- B-7576
- Dimensions
- 1.25 in H x 2.75 in W
- Dimensions 2
- 1.25 in H x 2.75 in W
- Height (mm/cm/m)
- 31.75 mm
- Maximum Service Temperature °C
- 100 °C
- Minimum Application Temperature °C
- 4 °C
- Minimum Service Temperature °C
- -70 °C
- Printable Area Dimensions (Metric)
- 31.75 mm H x 69.85 mm W
- Printable Area Width (mm/cm/m)
- 69.85 mm
- Size - Width (mm)
- 69.85 mm
- Thickness (mm/cm/m)
- 0.071 mm
- Vertical Repeat (mm)
- 34.93 mm
- Width (in/ft/yd)
- 2.75 in
Brand NameBrady®
ColorSilver
DiagramIcon 3 (triangle)
FinishMatte
Label/Media FormatRoll
Print TechnologyThermal Transfer
Printer CompatibilityBBP12; BBP11; BP1244; BP1344; BP2461; BP3481; BP6441; MVP200; MVP300; 300XPlusII; 360XPlusII; 600XPlusII; PR200Plus; PR300Plus; PR600Plus; IP300; IP600; i7100; i5100
Quantity per Roll3000
Recommended RibbonIP-R6002; R6002
ShapeRectangle
Tamper Indication TypeTamper-evident
Total Quantity3000
Adhesive (Y/N)Yes
Brady Material NumberB-7576
MaterialTamper-evident Metallized Polyester
Resistance PropertiesChemical-Resistant; Humidity-Resistant; UV-Resistant; Weather-Resistant
Core Diameter (mm/cm/m)76.20 mm
Dimensions (Metric)69.85 mm W x 31.75 mm H
Height (in/ft/yd)1.25 in
Label/Tape Size (in/ft/yd)1.25 in H x 2.75 in W
Maximum Service Temperature °F212 °F
Minimum Application Temperature °F39 °F
Minimum Service Temperature °F-94 °F
Printable Area Height (mm/cm/m)31.75 mm
Sign Size-General1.25 in x 2.75 in
Thickness (in/ft/yd)0.0028 in
Vertical Repeat1.375 in
Web Width (mm/cm/m)74.93 mm
Width (mm/cm/m)69.85 mm
Regulatory Information
- Contains CA PROP 65 Substance
- No - Does not contain
- Contains Heavy Metal(s)
- Unavailable
- EU RoHS Compliance
- Pass 2011/65/EU(Pass 2015/863)
- SDS Safety Data Sheet required
- No = MSDS/SDS is not required
Contains CA PROP 65 SubstanceNo
DOT Regulated ProductNo = not regulated by DOT
EU RoHS CompliantYes
