Hubbell Wiring Device-Kellems HBL988 Gangable Wall Box, 6-Gang, 4 Inch Depth, Pre-Galvanized Steel
- MPN: HBL988
- UPC: 783585459783
- PPN: HBL-HBL988
- UNSPSC: 39121309
CAD
$114.89
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Wall Boxes, Data Box, Gangable, 6- Gang, 4" Depth, 2" KOs
Features
- Large 2" Knockout for Connectorized Cables
- Ideal for delivering power, data and AV side-by-side
- Accepts industry standard wallplates for consistent appearance
- Includes Raised Grounding Screws
- Accepts HBL989 or HBL989AVD Low Voltage Dividers
- 154 Cu.In. Capacity
- Gangable design allows for design installation and flexibility;4 inch depth accommodates large cables and required bend radii
Specifications
Key Specifications
| Country of Origin | China |
|---|---|
| Width | 4.700 in |
| Mounting Method | Integral Mounting Bracket |
| Application | Flush mount in wall |
| Knockouts | Top KOs- (6 1/2", (6) 1/2"-3/4" TKO. Bottom KOs- (1) 1/2", 1/2"-3/4" TKO, (2) 1", 1-1/4", 1-1/2", and 2". Back KOs- (6) 1/2"-3/4" TKO |
| Special Features | Gangable design allows for design installation and flexibility;4 inch depth accommodates large cables and required bend radii |
| Sub Brand | Wall Boxes |
| Engineering Drawing 1 Display Text | HBL988 AutoCAD Drawing |
| Class Code | A36 |
| Freight Class Code | 06168002 |
| Image Actual Or Representative | A |
| Sub Class Code | A36A330 |
| Base Unit of Measure | EA |
| Carton - Gross Weight per Pack | 20.850 lb. |
| Carton - Pack Description | Carton |
| Carton - Total Units | 6 EA |
| Application - For Use On | Wall |
|---|---|
| Industry Standard(s) | cULus Listed |
| Size | 6-Gang |
| Color | Natural |
| Material | Pre Galvanzied Steel |
| Standard | cULus Listed |
| Type | Boxes |
| Construction Material - Main | Pre Galvanzied Steel |
| Description - Invoice | 6G WALLBOX, GANGABLE, 4INCH DEEP, 2IN KO |
| Harmonization Code | 7326908688 |
| MSDS Flag | No |
| Series | Gangable |
| BOX SIZE | 6.600x13.300x9.700 (in) |
| Carton - Number of Sub Packs | 6 |
| Carton - SCC-14 Next Lower Level Sub Pack | 00783585459783 |
| NAICS Code | 3359326101 |
Certifications
| Certified Listed | cULus Listed |
|---|
