Schneider Electric ZB5AA1 Harmony XB5 Non-Illuminated Push Button Head, 22mm, IP66/IP67/IP69K
- MPN: ZB5AA1
- PPN: SCH-ZB5AA1
CAD
$13.94
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
This Harmony XB5, flush white button head operates with a spring return mechanism. This button head provides an ergonomic interface for controlling your machines. It is easily installed and replaced on compatible complete push-button units and contact blocks via snap-fit assembly. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 / IP67 / IP69 / IP69K. It has a plastic bezel, this makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation. It is designed to fit in a standard 22mm cutout, ensuring compatibility when installing in pre-existing machinery. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.
Features
- This non-illuminated push button head features a standard 22mm mounting diameter, ensuring seamless physical compatibility with existing standard cutouts in your industrial control systems, machinery panels, and standard plastic control stations. Designed specifically for the Harmony XB5 series, it integrates natively with compatible contact blocks and mounting collars without requiring custom panel modifications or retrofitting.
- Engineered with high-performance industrial plastic and a robust spring return mechanism, this momentary operator boasts an exceptional mechanical durability rated for up to 10,000,000 cycles. This means you eliminate frequent maintenance cycles, prevent unplanned production downtime, and secure reliable, long-term switching performance in high-frequency operational environments.
- Featuring multi-certified IP66, IP67, IP69, and IP69K ratings alongside NEMA 4X, and 13 enclosure compliance, this flush white push button provides complete dust tight sealing and total waterproof protection against high-pressure, high-temperature washdowns. It is an ideal solution for applications demanding strict sanitary conditions or exposure to harsh outdoor elements.
- Constructed from premium, corrosion-resistant plastic, this basic element provides double electrical insulation and excellent chemical resistance against aggressive cleaning agents, oils, and industrial solvents. The impact-resistant and vibration-resistant engineering keeps the internal contacts safe and prevents accidental trips in heavy-duty manufacturing environments.
- Utilizing an unthreaded, snap-fit assembly design, this round signaling unit head installs effortlessly onto standard mounting bases and contact blocks without requiring complex tools. The clear, unmarked white flush profile provides a visually distinct, clean aesthetic at a distance, allowing you to easily apply custom external legend plates or text holders tailored to your specific system layout.
