Weidmuller 1474620000 WTR 4 GR

MPN: 1474620000
PPN: WDM-1474620000

$7.44

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

Test-disconnect terminal, Screw connection, 4 mm², 400 V, 32 A, Pivoting, grey

Documentation & Downloads

Specifications

Approvals

Approvals	CSA, DEMKOATEX, EAC, EXIKONF, GERMLLOYD, IECEXULD, KEMAKEUR, UR
UL File Number Search	E60693

ROHS	Conform

Dimensions And Weights

Width	6.1 mm
Height	60 mm
Depth	48 mm
Depth including DIN rail	49 mm

Width (inches)	0.24 inch
Height (inches)	2.362 inch
Depth (inches)	1.89 inch
Net weight	11.554 g

Csa Rating Data

Certificate No. (CSA)	200039-1057876
Voltage size C (CSA)	300 V
Wire cross section min. (CSA)	22 AWG

Current size C (CSA)	10 A
Wire cross section max. (CSA)	10 AWG

Additional Technical Data

Explosion-tested version	No
Open sides	right

Number of similar terminals	1
Type of mounting	Snap-on

Material Data

Material	Wemid
UL 94 flammability rating	V-0

Colour	grey

Safety Note

Safety notice	Safety Information

Classifications

ETIM 6.0	EC000902
eClass 9.0	27-14-11-26
eClass 10.0	27-14-11-26

ETIM 7.0	EC000902
eClass 9.1	27-14-11-26
UNSPSC	30-21-18-11

System Specifications

Version	Screw connection, Spacer, for plug-in cross-connector, One end without connector
Number of potentials	1
Number of clamping points per level	2
Levels cross-connected internally	No
Rail	TS 35
PE function	No

End cover plate required	Yes
Number of levels	1
Number of potentials per tier	1
PE connection	No
N-function	No
PEN function	No

Disconnect Terminals

Cross-disconnect	without
Slitting	Pivoting

Integral test socket	No

Temperatures

Storage temperature, max.	40 °C
Storage temperature	10 °C...40 °C
Continuous operating temp., max.	120 °C

Storage temperature, min.	10 °C
Continuous operating temp., min.	-50 °C

Rating Data

Rated cross-section	4 mm²
Rated current	32 A
Volume resistance according to IEC 60947-7-x	1 mΩ
Rated impulse withstand voltage	6 kV

Rated voltage	400 V
Current at maximum wires	32 A
Power loss in accordance with IEC 60947-7-x	1.02 W
Pollution severity	3

Rating Data Iecex/Atex

Certificate No. (ATEX)	DEMKO14ATEX1389U
Max. voltage (ATEX)	400 V
Wire cross section max. (ATEX)	4
Current (IECEX)	32 A
Marking EN 60079-7	Ex ec II C Gc

Certificate No. (IECEX)	IECEXUL14.0097U
Current (ATEX)	32 A
Max. voltage (IECEX)	400 V
Wire cross section max. (IECEX)	4 mm²
Ex 2014/34/EU label	II 3 G D

Conductors For Clamping (Rated Connection)

Blade size	0.6 x 3.5 mm
Clamping range, min.	0.22 mm²
Connection cross-section, stranded, max.	4 mm²
Connection direction	on side
Number of connections	2
Tightening torque, max.	0.6 Nm
Torque level with DMS electric screwdriver	2
Wire connection cross section AWG, max.	AWG 10
Wire connection cross section, finely stranded, max.	4 mm²
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, min.	0.5 mm²
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.	0.5 mm²
Wire connection cross-section, solid core, max.	6 mm²

Clamping range, max.	6 mm²
Clamping screw	M 3
Connection cross-section, stranded, min.	1.5 mm²
Gauge to IEC 60947-1	A4
Stripping length	13 mm
Tightening torque, min.	0.5 Nm
Type of connection	Screw connection
Wire connection cross section AWG, min.	AWG 22
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, max.	4 mm²
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.	2.5 mm²
Wire connection cross-section, finely stranded, min.	0.5 mm²
Wire connection cross-section, solid core, min.	0.5 mm²
