19 Inch Rack Mountable Fanpack Assembly, CFM Max 290, 115/230 VAC
nVent Hoffman

nVent Hoffman 2EB3500R115 19 Inch Rack Mountable Fanpack Assembly, CFM Max 290, 115/230 VAC

  • MPN: 2EB3500R115
  • UPC: 783510229245
  • PPN: HOF-2EB3500R115

CAD

$990.77

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Company Stock:

0

Looking to buy a large quantity?

To view product inventory

Spec sheet

Description

Designed for efficient temperature management, the nVent Hoffman 19 Inch Rack Mountable Fanpack Assembly effectively facilitates climate control for various enclosure applications. With a maximum airflow of 290 CFM and compatibility across 115/230 VAC, it ensures reliable operation within a wide range of environments, maintaining optimal conditions for sensitive equipment. The robust construction features a brushed aluminum grille and permanently lubricated ball bearing motors that promise longevity and performance, while the washable aluminum filter contributes to maintaining clean airflow. This assembly not only meets rigorous standards such as UL and CSA certifications but is also functionally tested to guarantee readiness right out of the box, making it an essential component for electrical enclosures requiring robust climate control solutions.

Features

  • Permanent, Washable Aluminum Filter
  • 19-in. Rack Mountable
  • Brushed Aluminum Grille
  • Exhaust Guard
  • Power Cord
  • Permanently lubricated ball bearing motors
  • 100% functionally tested
  • 115/230 VAC
  • 50/60 Hz

Documentation & Downloads

Specifications

Key Specifications

Model Code
22924
Catalog Number
2EB3500R115
B in.
19
Description
2EB3500R Model Fanpack Assembly
Max Current (A)
1.8
Fahrenheit Max.
104
Width (in.)
19.00
Weight (lb.)
17.00
Bulletin NumberMCLO
A in.5.25
C in.7.17
CFM Max290
Voltage100 - 120 VAC
Height (in.)5.25
Depth (in.)8.92
StandardsUL recognized || CSA Certified Motors || CE
