Brady 2HX-1000-2-GR-S PermaSleeve HX 3 Inch Heat Shrink Double-Sided Wire Marking Sleeves, 2:1 Shrink Ratio
- MPN: 2HX-1000-2-GR-S
- UPC: 662820653943
- PPN: BRD-2HX-1000-2-GR-S
CAD
$429.41
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Heat-Shrink PermaSleeve® HX Polyolefin (B-7642) Wire Marking Sleeves are 2:1 heat shrinkable, high-temperature rated, highly flame retardant and very flexible.
Features
- Supplied roll form in a flattened format on a carrier designed for use with computer driven printers
- RoHS compliant to 2005/618/EC MCV amendment to RoHS Directive 2002/95/EC; Meets SAE-AMS-DTL-23053/5 Class 1 & 3, SAE-AS-81531, MIL-STD-2002
- Tested per ASTM E162 and ASTM E662
- Operating temperature of -40°F to 248°F (-40°C to 120°C)
Specifications
Key Specifications
- Material Number
- B-7642
- Diameter as Supplied
- 1 in
- UOM
- Roll of 100 Each
- Maximum Service Temperature °F
- 248 °F
- Minimum Service Temperature °F
- -40 °F
- Minimum Wire Gauge
- 2/0 AWG
- Product Number
- 129845
- Quantity per Roll
- 100
- Recovered Diameter
- 0.5 in
- Shrink Ratio
- 2:1
- Sleeve Size(m)
- 25.4 mm Dia x 50.8 mm W
- Trade Name
- PermaSleeve®
- Color
- Green
- Label/Media Format
- Roll
- Material
- Polyolefin
- Print Technology
- Thermal Transfer
- Suggested Ribbon Series
- R4300, R6000, R6400, R6600
California Prop 65Cancer - || www.p65warnings.ca.gov
Dimensions1.66 in H
FinishMatte
Maximum Wire Diameter0.95 in
Minimum Wire Diameter0.5 in
Printable SidesDouble-Side Printable
UPC662820653943
Quantity per Row1
Roll Width2 in
Sleeve Size1 in Dia x 2 in W
Sleeve Width2 in
ApplicationsCable & Wire Marking
For Use with PrinterBBP®72 Label Printer, BradyPrinter i5100, BradyPrinter i7100, BRADYPRINTER PR Plus Series Label Printer, THT 3" Core Printer
Label PropertiesHeat Shrink Sleeves
Material PropertiesHeat-Shrinkable
Resistance PropertiesChemical-Resistant, Corrosion-Resistant, Humidity-Resistant, Self-Extinguishing, UV-Resistant, Weather-Resistant
