3M 5761 Cold Shrink Cable Splice, 15 kV, 2-3/0 AWG, 0.65-1 Inch O.D. Insulation, Inline Splice
- MPN: 5761
- UPC: 054007122609
- PPN: MMM-5761
CAD
$4000.33
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Cold Shrink Cable Splice, 15 kV, 2-3/0 AWG, 0.65-1 Inch O.D. Insulation, Inline Splice
Specifications
Key Specifications
| 3M ID | 80610154363 |
|---|---|
| Conductor Sizes for 15 kV | 1 AWG, 1/0 AWG, 2 AWG, 2/0 AWG, 3/0 AWG |
| Insulation O.D. Range | 0.65 - 1.00 Inch |
| Maximum Connector Length | 2.75 Inch |
| Number of Conductors | 3 |
| Product Technology | Cold Shrink, Resin |
| Shielding Type | Tape Shield |
| Trademark | 3M |
| Voltage | 15 kV, 5/8 kV |
| China RoHS - Below MCV | No |
|---|---|
| Conductor Sizes for 5_8 kV | 2/0 AWG, 250 kcmil, 3/0 AWG, 350 kcmil, 4/0 AWG |
| Insulation Outside Diameter Range | 0.65 - 1.00 Inch |
| Maximum Connector Length (metric) | 69.9 mm |
| Product Series | 5760 Series |
| Product Type | Splice |
| Splice Type | Inline |
| Typical Splice Length (metric) | 737 mm |
