Pass & Seymour PS460C7S 60A 3 Phase 480V Pin & Sleeve Connector, 10.75 Inch Length, Gray
- MPN: PS460C7S
- UPC: 785007460506
- PPN: P-S-PS460C7S
CAD
$815.38
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
3 Pole, 4 Wire Pin and Sleeve Connector, 60 Amp, 3 Phase 480 Volt
Features
- Legrand Pin & Sleeve products provide installation ease, enduring performance in harsh conditions, and guaranteed IEC 309 compatibility.
- Arrives ready to wire, with cord grip open and cable-ready. Terminal screws come backed out and ready to wire. Front and back body require no disassembly prior to assembly.
- Nylon construction for highimpact and corrosion resistance.
- Nickel-plated brass pins provide extracorrosion resistance without sacrificing electrical conductivity.
- Locking ring with an integral neoprene gasket provides watertight seal when plug and connector/receptacle are mated.
- Natural-rubber grommets provide watertight protection at cable entry.
- Combination-head screws for added convenience and quick installation.
- Revolutionary, hinged cord grip for durable performance and ease of installation.
- Cover with integral neoprene gasket provides watertight seal.
Documentation & Downloads
Specifications
Key Specifications
- Height
- 4.67 in
- Length
- 10.75 in
- Color
- Gray
- Country of Origin
- United States
- Voltage
- 480.0 V
- Standard
- UL Listed
- Number of Poles
- 3-Way
Special FeaturesPin & Sleeve devices, Nylon construction for high impact, combination head screws, rating compliance visible
Width3.78 in
Product LinePass & Seymour
Amperage60.0 A
Wire Size2 AWG
Number of Wires4.0
Application SectorCommercial
